BMW M5 Competition, BMW M5 and BMW M550i xDrive Saloon – engines, facts and dimensions.

The key facts and figures for the BMW 5 Series Saloon M Automobiles at a glance: find out all about engines, consumption, CO2 emissions and dimensions of the various BMW M5 models. Compare impressive performance data such as displacement, hp, Nm and acceleration – and discover which of these three exceptional sports saloons suits you best.

Read more

ENGINES AND TECHNICAL DATA OF THE BMW 5 SERIES SALOON M AUTOMOBILES.

Weight
Unladen weight EU in kg
1,970
Max. permissible weight in kg
2,440
Permitted load in kg
545
Permitted axle load front/rear in kg
1,215/1,260
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
8/4
Capacity in ccm
4,395
Stroke/bore in mm
88.3/89.0
Engine power in kW (hp) at 1/min
460 (625)/6,000
Engine torque (Nm) at 1/min
750/1,800-5,860
Compression ratio : 1
10.0
Performance
Top speed in km/h
250 (305)
Acceleration 0–100 km/h in s
3.3
Fuel consumption
Urban in l/100 km
15.6-15.3
Extra-urban in l/100 km
7.8-7.7
Combined in l/100 km
10.6-10.5
CO2 combined emissions in g/km
242-239
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
275/35 ZR20 (102Y)XL
Tyre dimensions rear
285/35 ZR20 (104Y)XL
Wheel dimensions and material front
9.5Jx20 inches, light-alloy
Wheel dimensions and material rear
10.5Jx20 inches, light-alloy
Weight
Unladen weight EU in kg
1,970
Max. permissible weight in kg
2,440
Permitted load in kg
545
Permitted axle load front/rear in kg
1,215/1,260
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
8/4
Capacity in ccm
4,395
Stroke/bore in mm
88.3/89.0
Engine power in kW (hp) at 1/min
441 (600)/6,000
Engine torque (Nm) at 1/min
750/1,800-5,600
Compression ratio : 1
10.0
Performance
Top speed in km/h
250 (305)
Acceleration 0–100 km/h in s
3.4
Fuel consumption
Urban in l/100 km
15.6-15.4
Extra-urban in l/100 km
7.7
Combined in l/100 km
10.6-10.5
CO2 combined emissions in g/km
242-239
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
275/40 ZR19 (105Y)XL
Tyre dimensions rear
285/40 ZR19 (107Y)XL
Wheel dimensions and material front
9.5Jx19 inches, light-alloy
Wheel dimensions and material rear
10.5Jx19 inches, light-alloy
Weight
Unladen weight EU in kg
1,990
Max. permissible weight in kg
2,560
Permitted load in kg
645
Permitted axle load front/rear in kg
1,260/1,365
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
8/4
Capacity in ccm
4.395
Stroke/bore in mm
88.3/89.0
Engine power in kW (hp) at 1/min
390 (530)/5,500-6,000
Engine torque (Nm) at 1/min
750/1,800-4,600
Compression ratio : 1
10.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
3.8
Fuel consumption
Urban in l/100 km
13.2-13.1
Extra-urban in l/100 km
8.1-7.7
Combined in l/100 km
10.0-9.7
CO2 combined emissions in g/km
229-221
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
245/40 R19 98 Y XL
Tyre dimensions rear
275/35 R19 100 Y XL
Wheel dimensions and material front
8Jx19 inches, light-alloy
Wheel dimensions and material rear
9Jx19 inches, light-alloy

Fuel consumption and CO2 emissions.

  • BMW M5 Competition:
    Fuel consumption in l/100 km (combined): 10.6–10.5
    CO2 emissions in g/km (combined): 242–239

    BMW M5:
    Fuel consumption in l/100 km (combined): 10.6–10.5
    CO2 emissions in g/km (combined): 242–239

    BMW M550i xDrive Saloon:
    Fuel consumption in l/100 km (combined): 10.0–9.7
    CO2 emissions in g/km (combined): 229–221

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles cars can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from The Society of the Irish Motor Industry, 5 Upper Pembroke Street, Dublin 2.
