BMW 5 SERIES TOURING: ENGINES & TECHNICAL DATA

The key facts and figures for the BMW 5 Series Touring at a glance: engines, consumption, CO2 emissions and dimensions. Check out all the performance data such as displacement, horsepower, torque and acceleration – and find out which engine best meets your needs.

Read more
THE 5BMW 5 SERIES TOURING: ENGINES & TECHNICAL DATA

TECHNICAL DATA.

System Power

System power in kW (hp) 215 (292)
Max. Torque (Nm) 420

BMW eDrive

Electric power 80 / 109
Max. torque (Nm) at 1/min 265

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,998
Stroke/Drilling in mm 94.6 / 82
Engine performance in kW (hp) 135 (184) / 5000-6500
Max torque(Nm) per 1/min 300 / 1350-4000
Compression:1 11

Range Charging

WLTP combined electric range in km 53 - 57
Battery type Li-Ion
Battery capacity 11.15
Charging duration AC 2.6
Charging duration in hrs (wallbox / public charging with max 3.7kW, 0-100%) 3.6
Charging duration in hrs (household socket 230V / 12.5A, 0-80%) 4.3
Charging duration in hrs (household socket 230V / 12.5A, 0-100%) 6

Performance

Top Speed 225
Top Speed Electric 140
Acceleration 6.1

Measurements

Length/Width/Height 4,963 / 1,868 / 1,498
Width incl. mirrors (driver / passenger side) in mm 2126 (1069 / 1057)
Wheelbase in mm/Wheel turn in m 2,975 / 12
Ground clearance in mm 143
Measurements
Measurements

Weight

Weight not loaded in kg 1,975
Weight Max in kg 2,550
Permitted load in kg 650
Permitted Axle load front/rear in kg 1,090 / 1,540
Allowed unbraked trailer load / drawbar load in kg 750 / 90
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,700 / 1,700
Trunk capacity min.-max. in l 430 - 1560

Wheels

Tire front 245/45 R18 100 Y XL
Tire rear 245/45 R18 100 Y XL
Rim front 8Jx18 LM
Rim rear 8Jx18 LM

Consumption

Electricity consumption in kWh/100km 22.2 - 23.8
Fuel consumption Weighted 1.5 - 1.8
Electric consumption AC Weighted 17 - 18
Tank capacity in l 46

CO2 Emissions

CO2 weighted 35 - 40

Fuel consumption and CO2 emissions.

  • The values for fuel consumption, CO2 emissions and energy consumption shown have been determined according to the WLTP test. WLTP has been used as the applicable fuel and energy consumption and CO2 emissions figure from 1 January 2021 for vehicle registration tax (VRT). The figures were previously based on the NEDC equivalent. Figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles and vehicle load. For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel. Plug-in hybrid and battery electric vehicles require mains electricity for charging. More information on the WLTP test procedure can be found here: https://www.bmw.ie/en/topics/fascination-bmw/efficient-dynamics/consumption-emissions.html

    A guide on fuel economy and CO2 emissions which contains data for all new passenger car models is available at any point of sale free of charge.
