THE ALL-NEW BMW 4 SERIES CONVERTIBLE: ENGINES & TECHNICAL DATA.

The key facts and figures on the new BMW 4 Series Convertible at a glance: engines, consumption, CO2 emissions and dimensions. Check out all the performance data such as displacement, horsepower, torque and acceleration – and find out which engine best meets your needs.

Read more
THE 4THE ALL-NEW BMW 4 SERIES CONVERTIBLE: ENGINES & TECHNICAL DATA.
BMW 4 Series Convertible

TECHNICAL DATA OF THE ALL-NEW BMW 4 SERIES CONVERTIBLE.

System Power

Fuel type Petrol
Power in kW (hp) 135 (184)
Torque in Nm 300
Gearbox 8-speed, automatic
Drivetrain Rear-wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 135 (184) / 5000 - 6500
Max torque(Nm) per 1/min 300 / 1350 - 4000

Performance

Maximum speed in km/h 236
Acceleration 0–100 km/h in s 8.2

Measurements

Length/Width/Height 4,768 / 1,852 / 1,384
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm 2,851 / 11.4
Ground clearance in mm 124
BMW 4 Series Convertible G23 technical data sketch
BMW 4 Series Convertible G23 technical data sketch

Weight

Weight not loaded in kg 1,765
Weight max in kg 2,185
Permitted load in kg 495
Permitted Axle load front/rear in kg 990 / 1,240
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 385

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel consumption, combined WLTP in l/100km 6.8 - 7.1
Fuel capacity in l 59

CO2 Emissions

CO2 emissions, combined WLTP in g/km 154 - 161

System Power

Fuel type Petrol
Power in kW (hp) 135 (184)
Torque in Nm 300
Gearbox 8-speed, automatic
Drivetrain Rear-wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 135 (184) / 5000 - 6500
Max torque(Nm) per 1/min 300 / 1350 - 4000

Performance

Maximum speed in km/h 236
Acceleration 0–100 km/h in s 8.2

Measurements

Length/Width/Height 4,768 / 1,852 / 1,384
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm 2,851 / 11.4
Ground clearance in mm 124
BMW 4 Series Convertible G23 technical data sketch
BMW 4 Series Convertible G23 technical data sketch

Weight

Weight not loaded in kg 1,765
Weight max in kg 2,185
Permitted load in kg 495
Permitted Axle load front/rear in kg 990 / 1,240
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 385

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel consumption, combined WLTP in l/100km 7 - 7.1
Fuel capacity in l 59

CO2 Emissions

CO2 emissions, combined WLTP in g/km 159 - 162

System Power

Fuel type Petrol – 48 Volt Mild-Hybrid
Power in kW (hp) 275 (374)
Torque in Nm 500
Gearbox 8-speed, automatic
Drivetrain All-wheel drive

BMW eDrive

Electric power 8 (11)
Nominal torque in Nm 25

Engine

Cylinder/ Valves per cylinder 6 / 4
Displacement in cm³ 2,998
Engine performance in kW (hp) 275 (374) / 5500 - 6500
Max torque(Nm) per 1/min 500 / 1900 - 5000

Performance

Maximum speed in km/h 250
Acceleration 0–100 km/h in s 4.9

Measurements

Length/Width/Height 4,770 / 1,852 / 1,394
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm 2,851 / 12
Ground clearance in mm 126
BMW 4 Series Convertible G23 technical data sketch
BMW 4 Series Convertible G23 technical data sketch

Weight

Weight not loaded in kg 1,965
Weight max in kg 2,390
Permitted load in kg 500
Permitted Axle load front/rear in kg 1,120 / 1,300
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 385

Wheels

Tire front 225/45 R18 95 Y XL
Tire rear 255/40 R18 99 Y XL
Rim front 7,5Jx18 LM
Rim rear 8,5Jx18 LM

Consumption

Fuel Consumption charge sustaining combined 8 - 8.1
Fuel capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 182 - 184

System Power

Fuel type Petrol
Power in kW (hp) 375 (510)
Torque in Nm 650
Gearbox 8-speed, automatic
Drivetrain All-wheel drive

Engine

Cylinder/ Valves per cylinder 6 / 4
Displacement in cm³ 2,993
Engine performance in kW (hp) 375 (510) / 6,250
Max torque(Nm) per 1/min 650 / 2750 - 5500

Performance

Maximum speed in km/h 250
Acceleration 0–100 km/h in s 3.7

Measurements

Length/Width/Height 4,794 / 1,887 / 1,395
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm 2,857 / 12.6
Ground clearance in mm 121
BMW 4 Series Convertible G23 technical data sketch
BMW 4 Series Convertible G23 technical data sketch

Weight

Weight not loaded in kg 1,995
Weight max in kg 2,345
Permitted load in kg 425
Permitted Axle load front/rear in kg 1,160 / 1,265
Luggage capacity in l 385

Wheels

Tire front 275/35 ZR19 (100Y) XL
Tire rear 285/30 ZR20 (99Y) XL
Rim front 9,5Jx19
Rim rear 10,5Jx20

Consumption

Fuel consumption, combined WLTP in l/100km 10.2
Fuel capacity in l 59

CO2 Emissions

CO2 emissions, combined WLTP in g/km 231 - 233

FUEL CONSUMPTION AND CO2 EMISSIONS OF THE BMW 4 SERIES CONVERTIBLE.

For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles after the battery had been fully charged. Plug-in hybrid and battery electric vehicles require mains electricity for charging. Figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles and vehicle load.

At temperatures below 0 degrees Celsius, the purely electric driving mode of plug-in hybrid models will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometres.
