BMW 3 Series Saloon (G20), technical data

THE 3

THE BMW 3 SERIES SALOON: ENGINES & TECHNICAL DATA

Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 3 Series Saloon.

Read more
THE 3THE BMW 3 SERIES SALOON: ENGINES & TECHNICAL DATA

TECHNICAL DATA OF THE BMW 3 SERIES SALOON.

System Power

System power in kW (hp) 215 (292)
Max. Torque (Nm) 420

BMW eDrive

Electric power 83 / 113
Max. torque (Nm) at 1/min 265

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,998
Stroke/Drilling in mm 94.6 / 82
Engine performance in kW (hp) 135 (184) / 5000-6500
Max torque(Nm) per 1/min 300 / 1350-4000
Compression:1 11

Range Charging

WLTP combined electric range in km 59 - 60
Battery type Li-Ion
Battery capacity 11.15
Charging duration AC 2.6
Charging duration in hrs (wallbox / public charging with max 3.7kW, 0-100%) 3.6
Charging duration in hrs (household socket 230V / 12.5A, 0-80%) 4.3
Charging duration in hrs (household socket 230V / 12.5A, 0-100%) 6

Performance

Top Speed 230
Top Speed Electric 140
Acceleration 5.8

Measurements

Length/Width/Height 4,709 / 1,827 / 1,444
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm/Wheel turn in m 2,851 / 11.4
Ground clearance in mm 147

Weight

Weight not loaded in kg 1,845
Weight Max in kg 2,300
Permitted load in kg 530
Permitted Axle load front/rear in kg 1,035 / 1,315
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,500 / 1,500
Trunk capacity min.-max. in l 375

Wheels

Tire front 225/50 R17 98 Y XL
Tire rear 225/50 R17 98 Y XL
Rim front 7,5Jx17 LM
Rim rear 7,5Jx17 LM

Consumption

Electricity consumption in kWh/100km 21 - 21.7
Fuel consumption Weighted 1.3 - 1.4
Electric consumption AC Weighted 16.5 - 16.9
Tank capacity in l 40

CO2 Emissions

CO2 weighted 30 - 32

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 330i Saloon:
Fuel consumption in l/100 km (combined): 7.3–6.4
CO2 emissions in g/km (combined): 166–147



Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more

Fuel consumption and CO2 emissions.

  • For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles after the battery had been fully charged. Plug-in hybrid and battery electric vehicles require mains electricity for charging. Figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles and vehicle load.

    At temperatures below 0 degrees Celsius, the purely electric driving mode of plug-in hybrid models will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometres.
