BMW 1 SERIES: ENGINES & TECHNICAL DATA.

Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW 1 Series.

Read more
THE 1BMW 1 SERIES: ENGINES & TECHNICAL DATA.

BMW 1 SERIES: TECHNICAL DATA.

OTR price from

System Power

Fuel type Petrol
System power in kW (hp) 100 (136)
Max. Torque (Nm) 220
Gearbox 6-speed, manual
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Top Speed 213
Acceleration 8.9

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,365
Weight Max in kg 1,845
Permitted load in kg 555
Permitted Axle load front/rear in kg 980 / 940
Allowed unbraked trailer load / drawbar load in kg 680 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 5.7 - 5.9
Tank capacity in l 42

CO2 Emissions

Combined in g/km 130 - 135

System Power

Fuel type Petrol
System power in kW (hp) 100 (136)
Max. Torque (Nm) 220
Gearbox 7-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Top Speed 213
Acceleration 8.8

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,395
Weight Max in kg 1,870
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,005 / 940
Allowed unbraked trailer load / drawbar load in kg 695 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 5.7 - 5.9
Tank capacity in l 42

CO2 Emissions

Combined in g/km 129 - 135

System Power

Fuel type Petrol
System power in kW (hp) 100 (136)
Max. Torque (Nm) 220
Gearbox 6-speed, manual
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Top Speed 213
Acceleration 8.9

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,365
Weight Max in kg 1,845
Permitted load in kg 555
Permitted Axle load front/rear in kg 980 / 940
Allowed unbraked trailer load / drawbar load in kg 680 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 5.7 - 6.1
Tank capacity in l 42

CO2 Emissions

Combined in g/km 130 - 138

System Power

Fuel type Petrol
System power in kW (hp) 100 (136)
Max. Torque (Nm) 220
Gearbox 7-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Top Speed 213
Acceleration 8.8

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,395
Weight Max in kg 1,870
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,005 / 940
Allowed unbraked trailer load / drawbar load in kg 695 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 5.7 - 6
Tank capacity in l 42

CO2 Emissions

Combined in g/km 130 - 138

System Power

Fuel type Petrol
System power in kW (hp) 100 (136)
Max. Torque (Nm) 220
Gearbox 6-speed, manual
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Top Speed 213
Acceleration 8.9

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,365
Weight Max in kg 1,845
Permitted load in kg 555
Permitted Axle load front/rear in kg 980 / 940
Allowed unbraked trailer load / drawbar load in kg 680 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Combined in l/100km 5.9 - 6.6
Tank capacity in l 42

CO2 Emissions

Combined in g/km 134 - 150

System Power

Fuel type Petrol
System power in kW (hp) 100 (136)
Max. Torque (Nm) 220
Gearbox 7-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Top Speed 213
Acceleration 8.8

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,395
Weight Max in kg 1,870
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,005 / 940
Allowed unbraked trailer load / drawbar load in kg 695 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Combined in l/100km 5.9 - 6.6
Tank capacity in l 42

CO2 Emissions

Combined in g/km 134 - 150

System Power

Fuel type Petrol
System power in kW (hp) 225 (306)
Max. Torque (Nm) 450
Gearbox 8-speed, automatic
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,998
Engine performance in kW (hp) 225 (306) / 5000 - 6250
Max torque(Nm) per 1/min 450 / 1800 - 4500

Performance

Top Speed 250
Acceleration 4.8

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,600
Weight Max in kg 2,085
Permitted load in kg 560
Permitted Axle load front/rear in kg 1,120 / 1,020
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 225/40 R18 92 Y XL
Tire rear 225/40 R18 92 Y XL
Rim front 8Jx18 LM
Rim rear 8Jx18 LM

Consumption

Combined in l/100km 7.4 - 7.9
Tank capacity in l 50

CO2 Emissions

Combined in g/km 168 - 179

System Power

Fuel type Petrol
System power in kW (hp) 195 (265)
Max. Torque (Nm) 400
Gearbox 8-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,998
Engine performance in kW (hp) 195 (265) / 4750 - 6500
Max torque(Nm) per 1/min 400 / 1750 - 4500

Performance

Top Speed 250
Acceleration 6.1

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,520
Weight Max in kg 2,000
Permitted load in kg 555
Permitted Axle load front/rear in kg 1,085 / 990
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 225/40 R18 92 Y XL
Tire rear 225/40 R18 92 Y XL
Rim front 8Jx18 LM
Rim rear 8Jx18 LM

Consumption

Combined in l/100km 6.9 - 7.4
Tank capacity in l 50

CO2 Emissions

Combined in g/km 157 - 170

System Power

Fuel type Diesel
System power in kW (hp) 85 (116)
Max. Torque (Nm) 270
Gearbox 6-speed, manual
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Top Speed 200
Acceleration 10.3

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,450
Weight Max in kg 1,925
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,025 / 980
Allowed unbraked trailer load / drawbar load in kg 725 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 4.6 - 4.8
Tank capacity in l 42

CO2 Emissions

Combined in g/km 120 - 125

System Power

Fuel type Diesel
System power in kW (hp) 85 (116)
Max. Torque (Nm) 270
Gearbox 7-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Top Speed 200
Acceleration 10.1

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,460
Weight Max in kg 1,940
Permitted load in kg 555
Permitted Axle load front/rear in kg 1,040 / 980
Allowed unbraked trailer load / drawbar load in kg 730 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 4.6 - 4.8
Tank capacity in l 42

CO2 Emissions

Combined in g/km 121 - 126

System Power

Fuel type Diesel
System power in kW (hp) 110 (150)
Max. Torque (Nm) 350
Gearbox 6-speed, manual
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 110 (150) / 4,000
Max torque(Nm) per 1/min 350 / 1750 - 2500

Performance

Top Speed 218
Acceleration 8.5

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,480
Weight Max in kg 1,950
Permitted load in kg 545
Permitted Axle load front/rear in kg 1,050 / 980
Allowed unbraked trailer load / drawbar load in kg 735 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 4.7 - 4.8
Tank capacity in l 42

CO2 Emissions

Combined in g/km 122 - 127

System Power

Fuel type Diesel
System power in kW (hp) 110 (150)
Max. Torque (Nm) 350
Gearbox 8-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 110 (150) / 4,000
Max torque(Nm) per 1/min 350 / 1750 - 2500

Performance

Top Speed 216
Acceleration 8.4

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,505
Weight Max in kg 1,980
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,080 / 980
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 4.9 - 5.1
Tank capacity in l 42

CO2 Emissions

Combined in g/km 128 - 132

System Power

Fuel type Diesel
System power in kW (hp) 85 (116)
Max. Torque (Nm) 270
Gearbox 6-speed, manual
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Top Speed 200
Acceleration 10.3

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,450
Weight Max in kg 1,925
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,025 / 980
Allowed unbraked trailer load / drawbar load in kg 725 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 4.6 - 4.9
Tank capacity in l 42

CO2 Emissions

Combined in g/km 121 - 128

System Power

Fuel type Diesel
System power in kW (hp) 85 (116)
Max. Torque (Nm) 270
Gearbox 7-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Top Speed 200
Acceleration 10.1

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,460
Weight Max in kg 1,940
Permitted load in kg 555
Permitted Axle load front/rear in kg 1,040 / 980
Allowed unbraked trailer load / drawbar load in kg 730 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 4.7 - 4.9
Tank capacity in l 42

CO2 Emissions

Combined in g/km 122 - 129

System Power

Fuel type Diesel
System power in kW (hp) 140 (190)
Max. Torque (Nm) 400
Gearbox 8-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 140 (190) / 4,000
Max torque(Nm) per 1/min 400 / 1750 - 2500

Performance

Top Speed 231
Acceleration 7.3

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,525
Weight Max in kg 2,000
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,085 / 985
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 225/45 R17 94 Y XL
Tire rear 225/45 R17 94 Y XL
Rim front 7,5Jx17 LM
Rim rear 7,5Jx17 LM

Consumption

Combined in l/100km 4.9 - 5.2
Tank capacity in l 50

CO2 Emissions

Combined in g/km 129 - 136

System Power

Fuel type Diesel
System power in kW (hp) 110 (150)
Max. Torque (Nm) 350
Gearbox 6-speed, manual
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 110 (150) / 4,000
Max torque(Nm) per 1/min 350 / 1750 - 2500

Performance

Top Speed 218
Acceleration 8.5

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,480
Weight Max in kg 1,950
Permitted load in kg 545
Permitted Axle load front/rear in kg 1,050 / 980
Allowed unbraked trailer load / drawbar load in kg 735 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 4.7 - 4.9
Tank capacity in l 42

CO2 Emissions

Combined in g/km 123 - 129

System Power

Fuel type Diesel
System power in kW (hp) 110 (150)
Max. Torque (Nm) 350
Gearbox 8-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 110 (150) / 4,000
Max torque(Nm) per 1/min 350 / 1750 - 2500

Performance

Top Speed 216
Acceleration 8.4

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,505
Weight Max in kg 1,980
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,080 / 980
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Combined in l/100km 4.9 - 5.2
Tank capacity in l 42

CO2 Emissions

Combined in g/km 128 - 135

System Power

Fuel type Diesel
System power in kW (hp) 140 (190)
Max. Torque (Nm) 400
Gearbox 8-speed, automatic
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 140 (190) / 4,000
Max torque(Nm) per 1/min 400 / 1750 - 2500

Performance

Top Speed 230
Acceleration 7

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,590
Weight Max in kg 2,065
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,105 / 1,020
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,500 / 1,500
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 225/45 R17 94 Y XL
Tire rear 225/45 R17 94 Y XL
Rim front 7,5Jx17 LM
Rim rear 7,5Jx17 LM

Consumption

Combined in l/100km 5.1 - 5.4
Tank capacity in l 50

CO2 Emissions

Combined in g/km 135 - 141

System Power

Fuel type Diesel
System power in kW (hp) 85 (116)
Max. Torque (Nm) 270
Gearbox 6-speed, manual
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Top Speed 200
Acceleration 10.3

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,450
Weight Max in kg 1,925
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,025 / 980
Allowed unbraked trailer load / drawbar load in kg 725 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Combined in l/100km 4.8 - 5.3
Tank capacity in l 42

CO2 Emissions

Combined in g/km 124 - 139

System Power

Fuel type Diesel
System power in kW (hp) 85 (116)
Max. Torque (Nm) 270
Gearbox 7-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Top Speed 200
Acceleration 10.1

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,460
Weight Max in kg 1,940
Permitted load in kg 555
Permitted Axle load front/rear in kg 1,040 / 980
Allowed unbraked trailer load / drawbar load in kg 730 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Combined in l/100km 4.8 - 5.3
Tank capacity in l 42

CO2 Emissions

Combined in g/km 125 - 140

System Power

Fuel type Diesel
System power in kW (hp) 110 (150)
Max. Torque (Nm) 350
Gearbox 6-speed, manual
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 110 (150) / 4,000
Max torque(Nm) per 1/min 350 / 1750 - 2500

Performance

Top Speed 218
Acceleration 8.5

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,480
Weight Max in kg 1,950
Permitted load in kg 545
Permitted Axle load front/rear in kg 1,050 / 980
Allowed unbraked trailer load / drawbar load in kg 735 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Combined in l/100km 4.8 - 5.4
Tank capacity in l 42

CO2 Emissions

Combined in g/km 126 - 141

System Power

Fuel type Diesel
System power in kW (hp) 110 (150)
Max. Torque (Nm) 350
Gearbox 8-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 110 (150) / 4,000
Max torque(Nm) per 1/min 350 / 1750 - 2500

Performance

Top Speed 216
Acceleration 8.4

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,505
Weight Max in kg 1,980
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,080 / 980
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Combined in l/100km 5 - 5.6
Tank capacity in l 42

CO2 Emissions

Combined in g/km 132 - 147

System Power

Fuel type Diesel
System power in kW (hp) 140 (190)
Max. Torque (Nm) 400
Gearbox 8-speed, automatic
Drive Type front wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 140 (190) / 4,000
Max torque(Nm) per 1/min 400 / 1750 - 2500

Performance

Top Speed 231
Acceleration 7.3

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,525
Weight Max in kg 2,000
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,085 / 985
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300 / 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Combined in l/100km 5.1 - 5.6
Tank capacity in l 50

CO2 Emissions

Combined in g/km 133 - 146

System Power

Fuel type Diesel
System power in kW (hp) 140 (190)
Max. Torque (Nm) 400
Gearbox 8-speed, automatic
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 140 (190) / 4,000
Max torque(Nm) per 1/min 400 / 1750 - 2500

Performance

Top Speed 230
Acceleration 7

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,590
Weight Max in kg 2,065
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,105 / 1,020
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,500 / 1,500
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Combined in l/100km 5.3 - 5.8
Tank capacity in l 50

CO2 Emissions

Combined in g/km 138 - 152
BMW WHEELS & TYRES.

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW M135i xDrive:
Fuel consumption in l/100 km (combined): 7.9–7.4
CO2 emissions in g/km (combined): 178–167



BMW 128ti:
Fuel consumption in l/100 km (combined): 7.5–6.8
CO2 emissions in g/km (combined): 178–168

Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more

Fuel consumption and CO2 emissions.

  • BMW M135i xDrive:
    Fuel consumption in l/100 km (combined): 7.9-7.4
    CO2 emissions in g/km (combined): 178-167

    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
