BMW 1 SERIES: TECHNICAL DATA.

System Power

Fuel type Petrol
Power in kW (hp) 100 (136)
Torque in Nm 220
Gearbox 6-speed, manual
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Maximum speed in km/h 213
Acceleration 0–100 km/h in s 8.9

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,365
Weight max in kg 1,845
Permitted load in kg 555
Permitted Axle load front/rear in kg 980 / 940
Allowed unbraked trailer load / drawbar load in kg 680 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Fuel consumption, combined WLTP in l/100km 5.7 - 5.9
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 130 - 135

System Power

Fuel type Petrol
Power in kW (hp) 100 (136)
Torque in Nm 220
Gearbox 7-speed, automatic
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Maximum speed in km/h 213
Acceleration 0–100 km/h in s 8.8

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,395
Weight max in kg 1,870
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,005 / 940
Allowed unbraked trailer load / drawbar load in kg 695 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Fuel consumption, combined WLTP in l/100km 5.7 - 5.9
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 129 - 135

System Power

Fuel type Petrol
Power in kW (hp) 100 (136)
Torque in Nm 220
Gearbox 6-speed, manual
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Maximum speed in km/h 213
Acceleration 0–100 km/h in s 8.9

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,365
Weight max in kg 1,845
Permitted load in kg 555
Permitted Axle load front/rear in kg 980 / 940
Allowed unbraked trailer load / drawbar load in kg 680 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Fuel consumption, combined WLTP in l/100km 5.7 - 6.1
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 130 - 138

System Power

Fuel type Petrol
Power in kW (hp) 100 (136)
Torque in Nm 220
Gearbox 7-speed, automatic
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Maximum speed in km/h 213
Acceleration 0–100 km/h in s 8.8

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,395
Weight max in kg 1,870
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,005 / 940
Allowed unbraked trailer load / drawbar load in kg 695 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Fuel consumption, combined WLTP in l/100km 5.7 - 6
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 130 - 138

System Power

Fuel type Petrol
Power in kW (hp) 100 (136)
Torque in Nm 220
Gearbox 6-speed, manual
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Maximum speed in km/h 213
Acceleration 0–100 km/h in s 8.9

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,365
Weight max in kg 1,845
Permitted load in kg 555
Permitted Axle load front/rear in kg 980 / 940
Allowed unbraked trailer load / drawbar load in kg 680 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Fuel consumption, combined WLTP in l/100km 5.9 - 6.6
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 134 - 150

System Power

Fuel type Petrol
Power in kW (hp) 100 (136)
Torque in Nm 220
Gearbox 7-speed, automatic
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,499
Engine performance in kW (hp) 100 (136) / 4500 - 6500
Max torque(Nm) per 1/min 220 / 1500 - 4100

Performance

Maximum speed in km/h 213
Acceleration 0–100 km/h in s 8.8

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,395
Weight max in kg 1,870
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,005 / 940
Allowed unbraked trailer load / drawbar load in kg 695 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Fuel consumption, combined WLTP in l/100km 5.9 - 6.6
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 134 - 150

System Power

Fuel type Petrol
Power in kW (hp) 195 (265)
Torque in Nm 400
Gearbox 8-speed, automatic
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 195 (265) / 4750 - 6500
Max torque(Nm) per 1/min 400 / 1750 - 4500

Performance

Maximum speed in km/h 250
Acceleration 0–100 km/h in s 6.1

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,520
Weight max in kg 2,000
Permitted load in kg 555
Permitted Axle load front/rear in kg 1,085 / 990
Luggage capacity in l 380 - 1200

Wheels

Tire front 225/40 R18 92 Y XL
Tire rear 225/40 R18 92 Y XL
Rim front 8Jx18 LM
Rim rear 8Jx18 LM

Consumption

Fuel consumption, combined WLTP in l/100km 6.9 - 7.4
Fuel capacity in l 50

CO2 Emissions

CO2 emissions, combined WLTP in g/km 157 - 170

System Power

Fuel type Petrol
Power in kW (hp) 225 (306)
Torque in Nm 450
Gearbox 8-speed, automatic
Drivetrain All-wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 225 (306) / 5000 - 6250
Max torque(Nm) per 1/min 450 / 1800 - 4500

Performance

Maximum speed in km/h 250
Acceleration 0–100 km/h in s 4.8

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,600
Weight max in kg 2,085
Permitted load in kg 560
Permitted Axle load front/rear in kg 1,120 / 1,020
Luggage capacity in l 380 - 1200

Wheels

Tire front 225/40 R18 92 Y XL
Tire rear 225/40 R18 92 Y XL
Rim front 8Jx18 LM
Rim rear 8Jx18 LM

Consumption

Fuel consumption, combined WLTP in l/100km 7.4 - 7.9
Fuel capacity in l 50

CO2 Emissions

CO2 emissions, combined WLTP in g/km 168 - 179

System Power

Fuel type Diesel
Power in kW (hp) 85 (116)
Torque in Nm 270
Gearbox 6-speed, manual
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Maximum speed in km/h 200
Acceleration 0–100 km/h in s 10.3

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,450
Weight max in kg 1,925
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,025 / 980
Allowed unbraked trailer load / drawbar load in kg 725 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Fuel consumption, combined WLTP in l/100km 4.6 - 4.8
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 120 - 125

System Power

Fuel type Diesel
Power in kW (hp) 85 (116)
Torque in Nm 270
Gearbox 7-speed, automatic
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Maximum speed in km/h 200
Acceleration 0–100 km/h in s 10.1

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,460
Weight max in kg 1,940
Permitted load in kg 555
Permitted Axle load front/rear in kg 1,040 / 980
Allowed unbraked trailer load / drawbar load in kg 730 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Fuel consumption, combined WLTP in l/100km 4.6 - 4.8
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 121 - 126

System Power

Fuel type Diesel
Power in kW (hp) 85 (116)
Torque in Nm 270
Gearbox 6-speed, manual
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Maximum speed in km/h 200
Acceleration 0–100 km/h in s 10.3

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,450
Weight max in kg 1,925
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,025 / 980
Allowed unbraked trailer load / drawbar load in kg 725 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Fuel consumption, combined WLTP in l/100km 4.6 - 4.9
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 121 - 128

System Power

Fuel type Diesel
Power in kW (hp) 85 (116)
Torque in Nm 270
Gearbox 7-speed, automatic
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Maximum speed in km/h 200
Acceleration 0–100 km/h in s 10.1

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,460
Weight max in kg 1,940
Permitted load in kg 555
Permitted Axle load front/rear in kg 1,040 / 980
Allowed unbraked trailer load / drawbar load in kg 730 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Fuel consumption, combined WLTP in l/100km 4.7 - 4.9
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 122 - 129

System Power

Fuel type Diesel
Power in kW (hp) 140 (190)
Torque in Nm 400
Gearbox 8-speed, automatic
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,995
Engine performance in kW (hp) 140 (190) / 4,000
Max torque(Nm) per 1/min 400 / 1750 - 2500

Performance

Maximum speed in km/h 231
Acceleration 0–100 km/h in s 7.3

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,525
Weight max in kg 2,000
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,085 / 985
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 225/45 R17 94 Y XL
Tire rear 225/45 R17 94 Y XL
Rim front 7,5Jx17 LM
Rim rear 7,5Jx17 LM

Consumption

Fuel consumption, combined WLTP in l/100km 4.9 - 5.2
Fuel capacity in l 50

CO2 Emissions

CO2 emissions, combined WLTP in g/km 129 - 136

System Power

Fuel type Diesel
Power in kW (hp) 85 (116)
Torque in Nm 270
Gearbox 6-speed, manual
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Maximum speed in km/h 200
Acceleration 0–100 km/h in s 10.3

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,450
Weight max in kg 1,925
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,025 / 980
Allowed unbraked trailer load / drawbar load in kg 725 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Fuel consumption, combined WLTP in l/100km 4.8 - 5.3
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 124 - 139

System Power

Fuel type Diesel
Power in kW (hp) 85 (116)
Torque in Nm 270
Gearbox 7-speed, automatic
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,496
Engine performance in kW (hp) 85 (116) / 4,000
Max torque(Nm) per 1/min 270 / 1750 - 2250

Performance

Maximum speed in km/h 200
Acceleration 0–100 km/h in s 10.1

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,460
Weight max in kg 1,940
Permitted load in kg 555
Permitted Axle load front/rear in kg 1,040 / 980
Allowed unbraked trailer load / drawbar load in kg 730 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Fuel consumption, combined WLTP in l/100km 4.8 - 5.3
Fuel capacity in l 42

CO2 Emissions

CO2 emissions, combined WLTP in g/km 125 - 140

System Power

Fuel type Diesel
Power in kW (hp) 140 (190)
Torque in Nm 400
Gearbox 8-speed, automatic
Drivetrain Front-wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,995
Engine performance in kW (hp) 140 (190) / 4,000
Max torque(Nm) per 1/min 400 / 1750 - 2500

Performance

Maximum speed in km/h 231
Acceleration 0–100 km/h in s 7.3

Measurements

Length/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm 2,670 / 11.4
Ground clearance in mm 153

Weight

Weight not loaded in kg 1,525
Weight max in kg 2,000
Permitted load in kg 550
Permitted Axle load front/rear in kg 1,085 / 985
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 380 - 1200

Wheels

Tire front 235/35 R19 91 Y XL
Tire rear 235/35 R19 91 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Fuel consumption, combined WLTP in l/100km 5.1 - 5.6
Fuel capacity in l 50

CO2 Emissions

CO2 emissions, combined WLTP in g/km 133 - 146
BMW WHEELS & TYRES.

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW M135i xDrive:
Fuel consumption in l/100 km (combined): 7.9–7.4
CO2 emissions in g/km (combined): 178–167



BMW 128ti:
Fuel consumption in l/100 km (combined): 7.5–6.8
CO2 emissions in g/km (combined): 178–168

Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more

Fuel consumption and CO2 emissions.

BMW M135i xDrive:
Fuel consumption in l/100 km (combined): 7.9-7.4
CO2 emissions in g/km (combined): 178-167

Read more

Fuel consumption and CO2 emissions.

  • BMW M135i xDrive:
    Fuel consumption in l/100 km (combined): 7.9-7.4
    CO2 emissions in g/km (combined): 178-167

    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
