BMW Z4 G29 2022 Thundernight technical data

THE Z4

BMW Z4 ROADSTER: ENGINES & TECHNICAL DATA.

THE Z4BMW Z4 ROADSTER: ENGINES & TECHNICAL DATA.

The key facts and figures for the BMW Z4 Roadster at a glance:


  • Engine, consumption and CO2 emissions
  • Performance data such as displacement, hp, Nm and acceleration
  • Weight, dimensions, wheel and tyre sizes
Read more

BMW Z4 ROADSTER: TECHNICAL DATA.

Select model

System Power

Fuel type Petrol
Power in kW (hp) 145 (197)
Torque in Nm 320
Gearbox 8-speed, automatic
Drivetrain Rear-wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 145 (197) / 4500 - 6500
Max torque(Nm) per 1/min 320 / 1450 - 4200

Performance

Maximum speed in km/h 240
Acceleration 0–100 km/h in s 6.6

Measurements

Length/Width/Height 4,324 / 1,864 / 1,304
Width incl. mirrors (driver / passenger side) in mm 2024 (1018 / 1006)
Wheelbase in mm 2,470 / 11
Ground clearance in mm 117
BMW Z4 Roadster G29 technical data drawing
BMW Z4 Roadster G29 technical data drawing

Weight

Weight not loaded in kg 1,525
Weight max in kg 1,740
Permitted load in kg 290
Permitted Axle load front/rear in kg 830 / 935
Luggage capacity in l 281

Wheels

Tire front 255/35 ZR19 96 Y XL
Tire rear 275/35 ZR19 100 Y XL
Rim front 9Jx19 LM
Rim rear 10Jx19 LM

Consumption

Fuel consumption, combined WLTP in l/100km 7.1 - 7.3
Fuel capacity in l 52

CO2 Emissions

CO2 emissions, combined WLTP in g/km 161 - 164

System Power

Fuel type Petrol
Power in kW (hp) 250 (340)
Torque in Nm 500
Drivetrain Rear-wheel drive

Engine

Cylinder/ Valves per cylinder 6 / 4
Displacement in cm³ 2,998
Engine performance in kW (hp) 250 (340) / 5000 - 6500
Max torque(Nm) per 1/min 500 / 1600 - 4500

Performance

Maximum speed in km/h 250
Acceleration 0–100 km/h in s 4.5

Measurements

Length/Width/Height 4,324 / 1,864 / 1,303
Width incl. mirrors (driver / passenger side) in mm 2024 (1018 / 1006)
Wheelbase in mm 2,470 / 11
Ground clearance in mm 114
BMW Z4 Roadster G29 technical data drawing
BMW Z4 Roadster G29 technical data drawing

Weight

Weight not loaded in kg 1,640
Weight max in kg 1,860
Permitted load in kg 295
Permitted Axle load front/rear in kg 880 / 995
Luggage capacity in l 281

Wheels

Tire front 255/40 ZR18 95 Y
Tire rear 275/40 ZR18 99 Y
Rim front 9Jx18 LM
Rim rear 10Jx18 LM

Consumption

Fuel consumption, combined WLTP in l/100km 8
Fuel capacity in l 52

CO2 Emissions

CO2 emissions, combined WLTP in g/km 180

System Power

Fuel type Petrol
Power in kW (hp) 250 (340)
Torque in Nm 500
Drivetrain Rear-wheel drive

Engine

Cylinder/ Valves per cylinder 6 / 4
Displacement in cm³ 2,998
Engine performance in kW (hp) 250 (340) / 5000 - 6500
Max torque(Nm) per 1/min 500 / 1600 - 4500

Performance

Maximum speed in km/h 250
Acceleration 0–100 km/h in s 4.6

Measurements

Length/Width/Height 4,324 / 1,864 / 1,303
Width incl. mirrors (driver / passenger side) in mm 2024 (1018 / 1006)
Wheelbase in mm 2,470 / 11
Ground clearance in mm 114
BMW Z4 Roadster G29 technical data drawing
BMW Z4 Roadster G29 technical data drawing

Weight

Weight not loaded in kg 1,625
Weight max in kg 1,860
Permitted load in kg 310
Permitted Axle load front/rear in kg 880 / 995
Luggage capacity in l 281

Wheels

Tire front 255/40 ZR18 95 Y
Tire rear 275/40 ZR18 99 Y
Rim front 9Jx18 LM
Rim rear 10Jx18 LM

Consumption

Fuel consumption, combined WLTP in l/100km 8.7
Fuel capacity in l 52

CO2 Emissions

CO2 emissions, combined WLTP in g/km 197
BMW WHEELS & TYRES.

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions.

BMW Z4 Roadster M40i[1]
Fuel consumption in l/100 km (combined): 8 - 7.9
CO2 emissions in g/km (combined): 181

[1] Values are preliminary

Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195.

For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the "Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.

Read more

Fuel consumption and CO2 emissions.

  • BMW Z4 Roadster M40i(1)
    Fuel consumption in l/100 km (combined): 8 - 7.9
    CO2 emissions in g/km (combined): 181

    (1)Values are preliminary

    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at  www.bmw.de/wltp
