BMW X5 G05 LCI

THE NEW X5

BMW X5: ENGINES & TECHNICAL DATA.

THE NEW X5BMW X5: ENGINES & TECHNICAL DATA.

The key facts and figures for the new BMW X5 at a glance:


  • Engine, consumption and CO2 emissions
  • Performance data such as displacement, kW/hp, Nm and acceleration
  • Weight, dimensions, wheel and tyre sizes
Read more

BMW X5: TECHNICAL DATA.

System Power

Fuel type Driving electric and with petrol
System power in kW (hp) 360 (489) "1"
Max. Torque (Nm) 700 "1"
Gearbox 8-speed, automatic
Drive Type all wheel drive

BMW eDrive

Electric power 145 (197)
Nominal torque in Nm 280

Engine

Cylinder/ Valves per cylinder 6 / 4
Technical capacity in cm3 2,998
Engine performance in kW (hp) 230 (313) / 5000 - 6500
Max torque(Nm) per 1/min 450 / 1750 - 4700

Range Charging

WLTP combined electric range in km 103 - 109
Max. charging performance AC in kW 7.4
Charging time AC in h, e.g. at BMW Wallbox, 0-100% state of charge (SOC) 4.5

Performance

Top Speed 250
Top Speed Electric 140
Acceleration 4.8

Measurements

Length/Width/Height 4,935 / 2,004 / 1,755
Width incl. mirrors (driver / passenger side) in mm 2218 (1122 / 1096)
Wheelbase in mm/Wheel turn in m 2,975 / 12.6
Ground clearance in mm 214

Weight

Weight not loaded in kg 2,495
Weight Max in kg 3,200
Permitted load in kg 780
Permitted Axle load front/rear in kg 1,400 / 1,875
Allowed unbraked trailer load / drawbar load in kg 750 / 140
Allowed braked trailer load up to 12 % / 8 % incline in kg 2,700 / 2,700
Trunk capacity min.-max. in l 500 - 1720

Wheels

Tire front 275/35 R22 104 Y XL
Tire rear 315/30 R22 107 Y XL
Rim front 9,5Jx22 LM
Rim rear 10,5Jx22 LM

Consumption

Fuel consumption Weighted 0.8 - 0.9
Electric consumption AC Weighted 23.2 - 24.6
Tank capacity in l 69

CO2 Emissions

CO2 weighted 18 - 21

System Power

Fuel type Petrol – 48 Volt Mild-Hybrid
System power in kW (hp) 390 (530)
Max. Torque (Nm) 750
Gearbox 8-speed, automatic
Drive Type all wheel drive

BMW eDrive

Electric power 9 (12)
Nominal torque in Nm 200

Engine

Cylinder/ Valves per cylinder 8 / 4
Technical capacity in cm3 4,395
Engine performance in kW (hp) 390 (530) / 5500 - 6000
Max torque(Nm) per 1/min 750 / 1800 - 4600

Performance

Top Speed 250
Acceleration 4.3

Measurements

Length/Width/Height 4,935 / 2,004 / 1,765
Width incl. mirrors (driver / passenger side) in mm 2218 (1122 / 1096)
Wheelbase in mm/Wheel turn in m 2,975 / 12
Ground clearance in mm 214

Weight

Weight not loaded in kg 2,420
Weight Max in kg 3,065
Permitted load in kg 720
Permitted Axle load front/rear in kg 1,430 / 1,680
Allowed unbraked trailer load / drawbar load in kg 750 / 140
Allowed braked trailer load up to 12 % / 8 % incline in kg 2,700 / 2,700
Trunk capacity min.-max. in l 650 - 1870

Wheels

Tire front 275/40 R21 107 Y XL
Tire rear 315/35 R21 111 Y XL
Rim front 9,5Jx21 LM
Rim rear 10,5Jx21 LM

Consumption

Fuel Consumption charge sustaining combined 11.6 - 11.9
Tank capacity in l 83

CO2 Emissions

CO2 charge sustaining combined 262 - 268

System Power

Fuel type Diesel – 48 Volt Mild-Hybrid
System power in kW (hp) 219 (298) "1"
Max. Torque (Nm) 670 "1"
Gearbox 8-speed, automatic
Drive Type all wheel drive

BMW eDrive

Electric power 9 (12)
Nominal torque in Nm 200

Engine

Cylinder/ Valves per cylinder 6 / 4
Technical capacity in cm3 2,993
Engine performance in kW (hp) 210 (286) / 4,000
Max torque(Nm) per 1/min 650 / 1500 - 2500

Performance

Top Speed 233
Acceleration 6.1

Measurements

Length/Width/Height 4,935 / 2,004 / 1,765
Width incl. mirrors (driver / passenger side) in mm 2218 (1122 / 1096)
Wheelbase in mm/Wheel turn in m 2,975 / 12.6
Ground clearance in mm 214

Weight

Weight not loaded in kg 2,295
Weight Max in kg 2,950
Permitted load in kg 730
Permitted Axle load front/rear in kg 1,360 / 1,680
Allowed unbraked trailer load / drawbar load in kg 750 / 140
Allowed braked trailer load up to 12 % / 8 % incline in kg 2,700 / 2,700
Trunk capacity min.-max. in l 650 - 1870

Wheels

Tire front 275/35 R22 104 Y XL
Tire rear 315/30 R22 107 Y XL
Rim front 9,5Jx22 LM
Rim rear 10,5Jx22 LM

Consumption

Fuel Consumption charge sustaining combined 7.2 - 7.6
Tank capacity in l 80

CO2 Emissions

CO2 charge sustaining combined 189 - 200

System Power

Fuel type Diesel – 48 Volt Mild-Hybrid
System power in kW (hp) 219 (298) "1"
Max. Torque (Nm) 670 "1"
Gearbox 8-speed, automatic
Drive Type all wheel drive

BMW eDrive

Electric power 9 (12)
Nominal torque in Nm 200

Engine

Cylinder/ Valves per cylinder 6 / 4
Technical capacity in cm3 2,993
Engine performance in kW (hp) 210 (286) / 4,000
Max torque(Nm) per 1/min 650 / 1500 - 2500

Performance

Top Speed 233
Acceleration 6.1

Measurements

Length/Width/Height 4,935 / 2,004 / 1,765
Width incl. mirrors (driver / passenger side) in mm 2218 (1122 / 1096)
Wheelbase in mm/Wheel turn in m 2,975 / 12.6
Ground clearance in mm 214

Weight

Weight not loaded in kg 2,295
Weight Max in kg 2,950
Permitted load in kg 730
Permitted Axle load front/rear in kg 1,360 / 1,680
Allowed unbraked trailer load / drawbar load in kg 750 / 140
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,900 / 1,900
Trunk capacity min.-max. in l 650 - 1870

Wheels

Tire front 265/50 R19 110 W XL
Tire rear 265/50 R19 110 W XL
Rim front 9Jx19 LM
Rim rear 9Jx19 LM

Consumption

Fuel Consumption charge sustaining combined 7.1 - 7.7
Tank capacity in l 80

CO2 Emissions

CO2 charge sustaining combined 186 - 201
BMW WHEELS & TYRES.

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions.

Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP.  In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometres.
