BMW XM G09 3/4 worm's eye view

THE XM

BMW XM G09 3/4 worm's eye view

TECHNICAL DATA OF THE BMW XM MODELS.

THE XMTECHNICAL DATA OF THE BMW XM MODELS.

The BMW XM Models – engines, facts and dimensions.

BMW XM MODELS: TECHNICAL DATA.

Select model
Select transmission

System Power

Fuel type Driving electric and with petrol
Power in kW (hp) 550 (748) "1"
Torque in Nm 1000 "1"
Gearbox 8-speed, automatic
Drivetrain All-wheel drive

BMW eDrive

Electric power 145 (197)
Nominal torque in Nm 280

Engine

Cylinder/ Valves per cylinder 8 / 4
Displacement in cm³ 4,395
Engine performance in kW (hp) 430 (585) / 5600 - 6500
Max torque(Nm) per 1/min 750 / 1800 - 5400

Range Charging

Electric range, WLTP in km 76 - 81
Max. charging performance AC in kW 7.4
Charging time AC in h, e.g. at BMW Wallbox, 0-100% state of charge (SOC) 4.25

Performance

Maximum speed in km/h 250
Top Speed Electric 140
Acceleration 0–100 km/h in s 3.8

Measurements

Length/Width/Height 5,110 / 2,005 / 1,755
Width incl. mirrors (driver / passenger side) in mm 2235 (1127 / 1108)
Wheelbase in mm 3,105 / 12.5
Ground clearance in mm 220

Weight

Weight not loaded in kg 2,795
Weight max in kg 3,300
Permitted load in kg 580
Permitted Axle load front/rear in kg 1,500 / 1,825
Allowed unbraked trailer load / drawbar load in kg 750 / 140
Luggage capacity in l 527 - 1820

Wheels

Tire front 275/45 R21 110 Y XL
Tire rear 315/40 R21 115 Y XL
Rim front 9,5Jx21 LM
Rim rear 10,5Jx21 LM

Consumption

Fuel consumption Weighted 1.7 - 2
Electric consumption AC Weighted 32.7 - 33.5
Fuel capacity in l 69

CO2 Emissions

CO2 weighted 37 - 45

System Power

Fuel type Driving electric and with petrol
Power in kW (hp) 480 (653) "1"
Torque in Nm 800 "1"
Gearbox 8-speed, automatic
Drivetrain All-wheel drive

BMW eDrive

Electric power 145 (197)
Nominal torque in Nm 280

Engine

Cylinder/ Valves per cylinder 8 / 4
Displacement in cm³ 4,395
Engine performance in kW (hp) 360 (489) / 5400 - 7200
Max torque(Nm) per 1/min 650 / 1600 - 5000

Range Charging

Electric range, WLTP in km 76 - 81
Max. charging performance AC in kW 7.4
Charging time AC in h, e.g. at BMW Wallbox, 0-100% state of charge (SOC) 4.25

Performance

Maximum speed in km/h 250
Top Speed Electric 140
Acceleration 0–100 km/h in s 4.3

Measurements

Length/Width/Height 5,110 / 2,005 / 1,755
Width incl. mirrors (driver / passenger side) in mm 2235 (1127 / 1108)
Wheelbase in mm 3,105 / 12.5
Ground clearance in mm 220

Weight

Weight not loaded in kg 2,785
Weight max in kg 3,300
Permitted load in kg 590
Permitted Axle load front/rear in kg 1,500 / 1,825
Allowed unbraked trailer load / drawbar load in kg 750 / 140
Luggage capacity in l 527 - 1820

Wheels

Tire front 275/45 R21 110 Y XL
Tire rear 315/40 R21 115 Y XL
Rim front 9,5Jx21 LM
Rim rear 10,5Jx21 LM

Consumption

Fuel consumption Weighted 1.6 - 1.9
Electric consumption AC Weighted 32.7 - 33.6
Fuel capacity in l 69

CO2 Emissions

CO2 weighted 37 - 43
BMW WHEELS & TYRES.

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions.

Figures shown are for comparability purposes; only compare fuel consumption and CO2 figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the accessories fitted (post-registration), variations in weather, driving styles and vehicle load.
