Technical data for the BMW 3 Series Touring M models.

¹
Powertrain type	Petrol
Power in kW (hp)	390 (530)
Torque in Nm	650
Transmission	8-speed, automatic
Drivetrain	All-wheel drive

¹
Cylinders	6
Displacement in cm³	2,993
Nominal power in kW (hp)/1/min	390 (530) / 6,250
Nominal torque in Nm/1/min	650 / 2,750 - 5,730


Acceleration 0–100 km/h in s	3.6 ²
Top speed in km/h	250

^{1 ,}³
Fuel consumption, combined WLTP in l/100km	10.4–10.3
CO2 emissions, combined WLTP in g/km	235–233
Pass-by noise in dB(A)	72 ⁵
Stationary noise level in dB(A) / 1/min	89 / 3,750 ⁵


4,801 mm
1,903 mm
1,446 mm
Length in mm	4,801
Width in mm	1,903
Height in mm	1,446
Width incl. mirrors (driver / passenger side) in mm	2,068
Wheelbase in mm	2,857
Vehicle curb weight in kg ⁴	1,940
Permissible gross weight in kg	2,370
Payload in kg	505
Luggage capacity in l	500–1,510
Tank capacity in l	59

¹
Powertrain type	Petrol
Power in kW (hp)	405 (551)
Torque in Nm	650
Transmission	8-speed, automatic
Drivetrain	All-wheel drive

¹
Cylinders	6
Displacement in cm³	2,993
Nominal power in kW (hp)/1/min	405 (551) / 6,250
Nominal torque in Nm/1/min	650 / 2,750 - 5,950


Acceleration 0–100 km/h in s	3.5 ²
Top speed in km/h	300

^{1 ,}³
Fuel consumption, combined WLTP in l/100km	10.5
CO2 emissions, combined WLTP in g/km	238
Pass-by noise in dB(A)	71 ⁵
Stationary noise level in dB(A) / 1/min	93 / 3,750 ⁵


4,796 mm
1,918 mm
1,447 mm
Length in mm	4,796
Width in mm	1,918
Height in mm	1,447
Width incl. mirrors (driver / passenger side) in mm	2,068
Wheelbase in mm	2,857
Vehicle curb weight in kg ⁴	1,925
Permissible gross weight in kg	2,330
Payload in kg	480
Luggage capacity in l	500–1,510
Tank capacity in l	59

¹
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW (hp)	275 (374)
Torque in Nm	500
Transmission	8-automatic
Drivetrain	All-wheel drive

¹
Cylinders	6
Displacement in cm³	2,998
Nominal power in kW (hp)/1/min	275 (374) / 5,500 - 6,500
Nominal torque in Nm/1/min	500 / 1,900 - 5,000


(Nominal) power/30-minutes-power in kW (hp)	8 (11) / -
(Nominal) torque in Nm	25


Acceleration 0–100 km/h in s	4.6 ²
Top speed in km/h	250

^{1 ,}³
Fuel consumption, combined WLTP in l/100km	8.8–8.1
CO2 emissions, combined WLTP in g/km	198–182

⁶
Battery capacity in kWh	0.4


4,714 mm
1,827 mm
1,440 mm
Length in mm	4,714
Width in mm	1,827
Height in mm	1,440
Wheelbase in mm	2,851
Vehicle curb weight in kg ⁴	1,870
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁷	1,800 / 75
Luggage capacity in l	500 - 1,510
Tank capacity in l	59

1 WLTP Figures shown are for comparability purposes. Only compare fuel consumption and CO2 figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the accessories fitted (post-registration), variations in weather, driving styles, fuel type and vehicle load.

2 Provisional figures; any missing figures were unavailable at the time of publication.

3 For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles these figures were obtained after the battery had been fully charged to 100%. Plug-in hybrid and battery electric vehicles require mains electricity for charging. WLTP figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles, fuel type and vehicle load.

4 The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

5 The values measured in accordance with UN/ECE Regulation No. 51/EU Regulation 540/2014 are rounded.

6 The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

7 Trailer load depends on the vehicle options
