THE M3

THE NEW BMW 3 SERIES SALOON M MODELS: ENGINES & TECHNICAL DATA.
The new BMW 3 Series Saloon M Models – engines, facts and dimensions.
BMW 3 SERIES SALOON M MODELS: TECHNICAL DATA.
- Diesel
- M340d xDrive Saloon
No search result found. Please try another input
Fuel type | Petrol |
---|---|
Power in kW (hp) | 375 (510) |
Torque in Nm | 650 |
Gearbox | 8-speed, automatic |
Drivetrain | Rear-wheel drive |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Displacement in cm³ | 2,993 |
Engine performance in kW (hp) | 375 (510) / 6,250 |
Max torque(Nm) per 1/min | 650 / 2750 - 5500 |
Maximum speed in km/h | 250 |
---|---|
Acceleration 0–100 km/h in s | 3.9 |
Length/Width/Height | 4,794 / 1,903 / 1,433 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm | 2,857 / 12.2 |
Ground clearance in mm | 120 |
Weight not loaded in kg | 1,805 |
---|---|
Weight max in kg | 2,210 |
Permitted load in kg | 480 |
Permitted Axle load front/rear in kg | 1,080 / 1,180 |
Luggage capacity in l | 480 |
Tire front | 275/40 ZR18 (103Y) XL |
---|---|
Tire rear | 285/35 ZR19 (103Y) XL |
Rim front | 9,5Jx18 |
Rim rear | 10,5Jx19 |
Fuel consumption, combined WLTP in l/100km | 9.8 |
---|---|
Fuel capacity in l | 59 |
CO2 emissions, combined WLTP in g/km | 223 - 224 |
---|
Fuel type | Petrol – 48 Volt Mild-Hybrid |
---|---|
Power in kW (hp) | 275 (374) |
Torque in Nm | 500 |
Gearbox | 8-speed, automatic |
Drivetrain | All-wheel drive |
Electric power | 8 (11) |
---|---|
Nominal torque in Nm | 25 |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Displacement in cm³ | 2,998 |
Engine performance in kW (hp) | 275 (374) / 5500 - 6500 |
Max torque(Nm) per 1/min | 500 / 1900 - 5000 |
Maximum speed in km/h | 250 |
---|---|
Acceleration 0–100 km/h in s | 4.4 |
Length/Width/Height | 4,714 / 1,827 / 1,440 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm | 2,851 / 12 |
Ground clearance in mm | 130 |
Weight not loaded in kg | 1,770 |
---|---|
Weight max in kg | 2,245 |
Permitted load in kg | 550 |
Permitted Axle load front/rear in kg | 1,115 / 1,230 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 75 |
Luggage capacity in l | 480 |
Tire front | 225/45 R18 95 Y XL |
---|---|
Tire rear | 255/40 R18 99 Y XL |
Rim front | 7,5Jx18 LM |
Rim rear | 8,5Jx18 LM |
Fuel Consumption charge sustaining combined | 8.1 - 8.2 |
---|---|
Fuel capacity in l | 59 |
CO2 charge sustaining combined | 182 - 184 |
---|
Fuel type | Petrol |
---|---|
Power in kW (hp) | 375 (510) |
Torque in Nm | 650 |
Gearbox | 8-speed, automatic |
Drivetrain | All-wheel drive |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Displacement in cm³ | 2,993 |
Engine performance in kW (hp) | 375 (510) / 6,250 |
Max torque(Nm) per 1/min | 650 / 2750 - 5500 |
Maximum speed in km/h | 250 |
---|---|
Acceleration 0–100 km/h in s | 3.5 |
Length/Width/Height | 4,794 / 1,903 / 1,434 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm | 2,857 / 12.6 |
Ground clearance in mm | 122 |
Weight not loaded in kg | 1,855 |
---|---|
Weight max in kg | 2,260 |
Permitted load in kg | 480 |
Permitted Axle load front/rear in kg | 1,125 / 1,200 |
Luggage capacity in l | 480 |
Tire front | 275/35 ZR19 (100Y) XL |
---|---|
Tire rear | 285/30 ZR20 (99Y) XL |
Rim front | 9,5Jx19 |
Rim rear | 10,5Jx20 |
Fuel consumption, combined WLTP in l/100km | 10 - 10.1 |
---|---|
Fuel capacity in l | 59 |
CO2 emissions, combined WLTP in g/km | 228 - 230 |
---|
Fuel type | Diesel – 48 Volt Mild-Hybrid |
---|---|
Power in kW (hp) | 250 (340) |
Torque in Nm | 700 |
Gearbox | 8-speed, automatic |
Drivetrain | All-wheel drive |
Electric power | 8 (11) |
---|---|
Nominal torque in Nm | 25 |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Displacement in cm³ | 2,993 |
Engine performance in kW (hp) | 250 (340) / 4,400 |
Max torque(Nm) per 1/min | 700 / 1750 - 2250 |
Maximum speed in km/h | 250 |
---|---|
Acceleration 0–100 km/h in s | 4.6 |
Length/Width/Height | 4,713 / 1,827 / 1,445 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm | 2,851 / 12 |
Ground clearance in mm | 135 |
Weight not loaded in kg | 1,875 |
---|---|
Weight max in kg | 2,340 |
Permitted load in kg | 540 |
Permitted Axle load front/rear in kg | 1,155 / 1,260 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 75 |
Luggage capacity in l | 480 |
Tire front | 225/45 R18 95 Y XL |
---|---|
Tire rear | 255/40 R18 99 Y XL |
Rim front | 7,5Jx18 LM |
Rim rear | 8,5Jx18 LM |
Fuel Consumption charge sustaining combined | 6.1 |
---|---|
Fuel capacity in l | 59 |
CO2 charge sustaining combined | 159 - 161 |
---|
Fuel consumption and CO2 emissions.
BMW M3 CS:
Fuel consumption, combined WLTP in l/100 km: 10.4–10.1
CO2 emissions, combined WLTP in g/km: 234–229
BMW M3 Competition Saloon with M xDrive:
Fuel consumption, combined WLTP in l/100 km: 10.1–10.0
CO2 emissions, combined WLTP in g/km: 230–228
BMW M3 Competition Saloon:
Fuel consumption, combined WLTP in l/100 km: 9.8
CO2 emissions, combined WLTP in g/km: 224–223
BMW M3 Saloon:
Fuel consumption, combined WLTP in l/100 km: 10.2–10.0
CO2 emissions, combined WLTP in g/km: 231–227
BMW M340i xDrive Saloon:
Fuel consumption, combined WLTP in l/100 km: 8.5–7.8
CO2 emissions, combined WLTP in g/km: 192–177
BMW M340i Saloon:
Fuel consumption, combined WLTP in l/100 km: 8.5–7.8(1)
CO2 emissions, combined WLTP in g/km: 192–177(1)
BMW M340d xDrive Saloon:
Fuel consumption, combined WLTP in l/100 km: 6.4–5.9
CO2 emissions, combined WLTP in g/km: 169–154
(1) Provisional figures
Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
FUEL CONSUMPTION AND CO2 EMISSIONS.
BMW M3 CS:
Fuel consumption, combined WLTP in l/100 km: 10.2–10.3
CO2 emissions, combined WLTP in g/km: 230–232
BMW M3 Competition Saloon with M xDrive:
Fuel consumption, combined WLTP in l/100 km: 10–10.1
CO2 emissions, combined WLTP in g/km: 228–230
BMW M3 Competition Saloon:
Fuel consumption, combined WLTP in l/100 km: 9.8
CO2 emissions, combined WLTP in g/km: 223–224
BMW M3 Saloon:
Fuel consumption, combined WLTP in l/100 km: 10.2–10.0
CO2 emissions, combined WLTP in g/km: 231–227
BMW M340i xDrive Saloon:
Fuel consumption, combined WLTP in l/100 km: 8.1–8.2
CO2 emissions, combined WLTP in g/km: 182–184
BMW M340d xDrive Saloon:
Fuel consumption, combined WLTP in l/100 km: 6.1
CO2 emissions, combined WLTP in g/km: 159–161
[1] Provisional figures
Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
