TECHNICAL DATA OF THE BMW 4 SERIES COUPÉ.

System Power

Fuel Type Petrol
Drive Type rear wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,998
Engine performance in kW (hp) 135 (184) / 5000-6500
Max torque(Nm) per 1/min 300 / 1350-4000

Performance

Top Speed 240
Acceleration 7.5

Measurements

Length/Width/Height 4,768 / 1,852 / 1,383
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 11.4
Ground clearance in mm 127

Weight

Weight not loaded in kg 1,600
Weight Max in kg 2,015
Permitted load in kg 490
Permitted Axle load front/rear in kg 970 / 1,120
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,600 / 1,600
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Combined in l/100km 6.4 - 6.7
Tank capacity in l 59

CO2 Emissions

Combined in g/km 146 - 153

System Power

Fuel Type Petrol
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,998
Engine performance in kW (hp) 135 (184) / 5000-6500
Max torque(Nm) per 1/min 300 / 1350-4000

Performance

Top Speed 238
Acceleration 7.8

Measurements

Length/Width/Height 4,768 / 1,852 / 1,390
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 12
Ground clearance in mm 126

Weight

Weight not loaded in kg 1,665
Weight Max in kg 2,080
Permitted load in kg 490
Permitted Axle load front/rear in kg 1,020 / 1,130
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,800 / 1,800
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Combined in l/100km 6.8 - 7.1
Tank capacity in l 59

CO2 Emissions

Combined in g/km 154 - 161

System Power

Fuel Type Petrol
Drive Type rear wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,998
Engine performance in kW (hp) 180 (245) / 4500-6500
Max torque(Nm) per 1/min 400 / 1600-4000

Performance

Top Speed 250
Acceleration 5.9

Measurements

Length/Width/Height 4,768 / 1,852 / 1,383
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 11.4
Ground clearance in mm 127

Weight

Weight not loaded in kg 1,620
Weight Max in kg 2,030
Permitted load in kg 485
Permitted Axle load front/rear in kg 980 / 1,120
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,600 / 1,600
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Combined in l/100km 6.7 - 7
Tank capacity in l 59

CO2 Emissions

Combined in g/km 153 - 160

System Power

Fuel Type Petrol
Drive Type rear wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,998
Engine performance in kW (hp) 135 (184) / 5000-6500
Max torque(Nm) per 1/min 300 / 1350-4000

Performance

Top Speed 240
Acceleration 7.5

Measurements

Length/Width/Height 4,768 / 1,852 / 1,383
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 11.4
Ground clearance in mm 127

Weight

Weight not loaded in kg 1,600
Weight Max in kg 2,015
Permitted load in kg 490
Permitted Axle load front/rear in kg 970 / 1,120
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,600 / 1,600
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Combined in l/100km 6.6 - 6.7
Tank capacity in l 59

CO2 Emissions

Combined in g/km 150 - 153

System Power

Fuel Type Petrol
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,998
Engine performance in kW (hp) 135 (184) / 5000-6500
Max torque(Nm) per 1/min 300 / 1350-4000

Performance

Top Speed 238
Acceleration 7.8

Measurements

Length/Width/Height 4,768 / 1,852 / 1,390
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 12
Ground clearance in mm 126

Weight

Weight not loaded in kg 1,665
Weight Max in kg 2,080
Permitted load in kg 490
Permitted Axle load front/rear in kg 1,020 / 1,130
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,800 / 1,800
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Combined in l/100km 7 - 7.1
Tank capacity in l 59

CO2 Emissions

Combined in g/km 159 - 161

System Power

Fuel Type Petrol
Drive Type rear wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,998
Engine performance in kW (hp) 180 (245) / 4500-6500
Max torque(Nm) per 1/min 400 / 1600-4000

Performance

Top Speed 250
Acceleration 5.9

Measurements

Length/Width/Height 4,768 / 1,852 / 1,383
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 11.4
Ground clearance in mm 127

Weight

Weight not loaded in kg 1,620
Weight Max in kg 2,030
Permitted load in kg 485
Permitted Axle load front/rear in kg 980 / 1,120
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,600 / 1,600
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Combined in l/100km 6.9 - 7
Tank capacity in l 59

CO2 Emissions

Combined in g/km 157 - 160

System Power

Fuel Type Petrol - 48V Mild-Hybrid
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 6 / 4
Technical capacity in cm3 2,998
Engine performance in kW (hp) 275 (374) / 5500-6500
Max torque(Nm) per 1/min 500 / 1900-5000

Performance

Top Speed 250
Acceleration 4.5

Measurements

Length/Width/Height 4,770 / 1,852 / 1,393
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 12
Ground clearance in mm 129

Weight

Weight not loaded in kg 1,815
Weight Max in kg 2,245
Permitted load in kg 505
Permitted Axle load front/rear in kg 1,110 / 1,190
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,800 / 1,800
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/45 R18 95 Y XL
Tire rear 255/40 R18 99 Y XL
Rim front 7,5Jx18 LM
Rim rear 8,5Jx18 LM

Consumption

Fuel Consumption charge sustaining combined 7.7 - 7.8
Tank capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 175 - 178

System Power

Fuel Type Diesel - 48V Mild-Hybrid
Drive Type rear wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 140 (190) / 4000
Max torque(Nm) per 1/min 400 / 1750-2500

Performance

Top Speed 240
Acceleration 7.1

Measurements

Length/Width/Height 4,768 / 1,852 / 1,383
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 11.4
Ground clearance in mm 127

Weight

Weight not loaded in kg 1,680
Weight Max in kg 2,095
Permitted load in kg 490
Permitted Axle load front/rear in kg 1,020 / 1,160
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,600 / 1,600
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel Consumption charge sustaining combined 4.7 - 5
Tank capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 122 - 130

System Power

Fuel Type Diesel - 48V Mild-Hybrid
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 140 (190) / 4000
Max torque(Nm) per 1/min 400 / 1750-2500

Performance

Top Speed 238
Acceleration 7.4

Measurements

Length/Width/Height 4,768 / 1,852 / 1,390
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 12
Ground clearance in mm 126

Weight

Weight not loaded in kg 1,745
Weight Max in kg 2,165
Permitted load in kg 495
Permitted Axle load front/rear in kg 1,070 / 1,170
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,800 / 1,800
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel Consumption charge sustaining combined 5 - 5.3
Tank capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 131 - 139

System Power

Fuel Type Diesel - 48V Mild-Hybrid
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 6 / 4
Technical capacity in cm3 2,993
Engine performance in kW (hp) 210 (286) / 4000
Max torque(Nm) per 1/min 650 / 1500-2500

Performance

Top Speed 250
Acceleration 5.1

Measurements

Length/Width/Height 4,768 / 1,852 / 1,390
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 12
Ground clearance in mm 126

Weight

Weight not loaded in kg 1,855
Weight Max in kg 2,285
Permitted load in kg 505
Permitted Axle load front/rear in kg 1,150 / 1,200
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,800 / 1,800
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel Consumption charge sustaining combined 5.4 - 5.6
Tank capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 140 - 147

System Power

Fuel Type Diesel - 48V Mild-Hybrid
Drive Type rear wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 140 (190) / 4000
Max torque(Nm) per 1/min 400 / 1750-2500

Performance

Top Speed 240
Acceleration 7.1

Measurements

Length/Width/Height 4,768 / 1,852 / 1,383
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 11.4
Ground clearance in mm 127

Weight

Weight not loaded in kg 1,680
Weight Max in kg 2,095
Permitted load in kg 490
Permitted Axle load front/rear in kg 1,020 / 1,160
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,600 / 1,600
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel Consumption charge sustaining combined 4.8 - 5
Tank capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 127 - 130

System Power

Fuel Type Diesel - 48V Mild-Hybrid
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Technical capacity in cm3 1,995
Engine performance in kW (hp) 140 (190) / 4000
Max torque(Nm) per 1/min 400 / 1750-2500

Performance

Top Speed 238
Acceleration 7.4

Measurements

Length/Width/Height 4,768 / 1,852 / 1,390
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 12
Ground clearance in mm 126

Weight

Weight not loaded in kg 1,745
Weight Max in kg 2,165
Permitted load in kg 495
Permitted Axle load front/rear in kg 1,070 / 1,170
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,800 / 1,800
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel Consumption charge sustaining combined 5.2 - 5.3
Tank capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 136 - 139

System Power

Fuel Type Diesel - 48V Mild-Hybrid
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 6 / 4
Technical capacity in cm3 2,993
Engine performance in kW (hp) 210 (286) / 4000
Max torque(Nm) per 1/min 650 / 1500-2500

Performance

Top Speed 250
Acceleration 5.1

Measurements

Length/Width/Height 4,768 / 1,852 / 1,390
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 12
Ground clearance in mm 126

Weight

Weight not loaded in kg 1,855
Weight Max in kg 2,285
Permitted load in kg 505
Permitted Axle load front/rear in kg 1,150 / 1,200
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,800 / 1,800
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel Consumption charge sustaining combined 5.5 - 5.6
Tank capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 145 - 147

System Power

Fuel Type Diesel - 48V Mild-Hybrid
Drive Type all wheel drive

Engine

Cylinder/ Valves per cylinder 6 / 4
Technical capacity in cm3 2,993
Engine performance in kW (hp) 250 (340) / 4400
Max torque(Nm) per 1/min 700 / 1750-2250

Performance

Top Speed 250
Acceleration 4.6

Measurements

Length/Width/Height 4,770 / 1,852 / 1,393
Width incl. mirrors (driver / passenger side) in mm 2081 (1046 / 1035)
Wheelbase in mm/Wheel turn in m 2,851 / 12
Ground clearance in mm 129

Weight

Weight not loaded in kg 1,905
Weight Max in kg 2,340
Permitted load in kg 510
Permitted Axle load front/rear in kg 1,170 / 1,225
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,800 / 1,800
Trunk capacity min.-max. in l 440

Wheels

Tire front 225/45 R18 95 Y XL
Tire rear 255/40 R18 99 Y XL
Rim front 7,5Jx18 LM
Rim rear 8,5Jx18 LM

Consumption

Fuel Consumption charge sustaining combined 5.9 - 6
Tank capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 154 - 157
BMW WHEELS & TYRES.

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW M440i xDrive Coupé:
Fuel consumption in l/100 km (combined): 8.5–8.0
CO2 emissions in g/km (combined): 194–181



Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more

FUEL CONSUMPTION AND CO2 EMISSIONS.

  • Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles cars can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from The Society of the Irish Motor Industry, 5 Upper Pembroke Street, Dublin 2.
