BMW X1 technical data

BMW X1

BMW X1: TECHNICAL DATA

BMW X1BMW X1: TECHNICAL DATA

Here you can find the technical data of the BMW X1.

Read more

TECHNICAL DATA.

Weight
Unladen weight EU in kg
1,400 [1,430]
Max. permissible weight in kg
2,000 [2,025]
Permitted load in kg
600 [595]
Permitted axle load front/rear in kg
990/1,035 [1,020/1,035]
Luggage capacity min. (seats up or roof down) in l
505 [505]
Luggage capacity max. (seats down or roof up) in l
1,550 [1,550]
Trailer load (unbraked) in kg
735 [750]
Trailer load 8% (braked) in kg
1,700 [1,700]
Trailer load 12% (braked) in kg
1,700 [1,700]
Engine
Cylinders/valves
3/4
Capacity in ccm
1,499
Stroke/bore in mm
94.6/82.0
Engine power in kW (PS) at 1/min
103 (140)/4,600-6,500
Engine torque (Nm) at 1/min
220/1,480-4,200
Compression ratio : 1
11.0
Performance
Top speed in km/h
205 [203]
Acceleration 0–100 km/h in s
9.7 [9.7]
Fuel consumption
Urban in l/100 km
7.3-6.9 [7.0-6.8]
Extra-urban in l/100 km
5.1-4.7 [4.9-4.6]
Combined in l/100 km
5.9-5.5 [5.9-5.4]
CO2 combined emissions in g/km
134-125 [129-122]
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
225/55 R17 97 W
Tyre dimensions rear
225/55 R17 97 W
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,570
Max. permissible weight in kg
2,155
Permitted load in kg
585
Permitted axle load front/rear in kg
1,080/1,100
Luggage capacity min. (seats up or roof down) in l
505
Luggage capacity max. (seats down or roof up) in l
1,550
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (PS) at 1/min
141 (192)/5,000-6,000
Engine torque (Nm) at 1/min
280/1,350-4,600
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
7.7
Fuel consumption
Urban in l/100 km
7.7
Extra-urban in l/100 km
6.1
Combined in l/100 km
6.7
CO2 combined emissions in g/km
152
Tank capacity, approx. in l
61
Wheels
Tyre dimensions front
225/55 R17 97W
Tyre dimensions rear
225/55 R17 97W
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,560
Max. permissible weight in kg
2,065
Permitted load in kg
550
Permitted axle load front/rear in kg
1,050/1,045
Luggage capacity min. (seats up or roof down) in l
505
Luggage capacity max. (seats down or roof up) in l
1,550
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (PS) at 1/min
141 (192)/5,000-6,000
Engine torque (Nm) at 1/min
280/1,350-4,600
Compression ratio : 1
11.0
Performance
Top speed in km/h
226
Acceleration 0–100 km/h in s
7.6
Fuel consumption
Urban in l/100 km
7.5
Extra-urban in l/100 km
5.1
Combined in l/100 km
6.0
CO2 combined emissions in g/km
136
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
225/55 R17 97W
Tyre dimensions rear
225/55 R17 97W
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,480 [1,500]
Max. permissible weight in kg
2,040 [2,040]
Permitted load in kg
550 [540]
Permitted axle load front/rear in kg
1,035/1,070 [1,065/1,070]
Luggage capacity min. (seats up or roof down) in l
505 [505]
Luggage capacity max. (seats down or roof up) in l
1,550 [1,550]
Trailer load (unbraked) in kg
750 [750]
Trailer load 8% (braked) in kg
1,700 [1,700]
Trailer load 12% (braked) in kg
1,700 [1,700]
Engine
Cylinders/valves
3/4
Capacity in ccm
1,496
Stroke/bore in mm
90.0/84.0
Engine power in kW (PS) at 1/min
85 (116)/4,000
Engine torque (Nm) at 1/min
270/1,750-2,250
Compression ratio : 1
16.5
Performance
Top speed in km/h
190 [190]
Acceleration 0–100 km/h in s
11.5 [11.5]
Fuel consumption
Urban in l/100 km
5.0-4.7 [4.8-4.6]
Extra-urban in l/100 km
4.1-3.8 [4.2-3.9]
Combined in l/100 km
4.4-4.1 [4.4-4.2]
CO2 combined emissions in g/km
116-107 [116-109]
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
225/55 R17 97W
Tyre dimensions rear
225/55 R17 97W
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,505 [1,540]
Max. permissible weight in kg
2,090 [2,125]
Permitted load in kg
585 [585]
Permitted axle load front/rear in kg
1,055/1,070 [1,095/1,070]
Luggage capacity min. (seats up or roof down) in l
505 [505]
Luggage capacity max. (seats down or roof up) in l
1,550 [1,550]
Trailer load (unbraked) in kg
750 [750]
Trailer load 8% (braked) in kg
1,800 [1,800]
Trailer load 12% (braked) in kg
1,800 [1,800]
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (PS) at 1/min
110 (150)/4,000
Engine torque (Nm) at 1/min
350/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
205 [205]
Acceleration 0–100 km/h in s
9.3 [9.4]
Fuel consumption
Urban in l/100 km
5.3-4.9 [5.2-4.9]
Extra-urban in l/100 km
4.2-3.9 [4.4-4.0]
Combined in l/100 km
4.6-4.3 [4.7-4.4]
CO2 combined emissions in g/km
121-113 [122-114]
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
225/55 R17 97 W
Tyre dimensions rear
225/55 R17 97 W
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,580 [1,605]
Max. permissible weight in kg
2,170 [2,190]
Permitted load in kg
590 [585]
Permitted axle load front/rear in kg
1,095/1,110 [1,115/1,110]
Luggage capacity min. (seats up or roof down) in l
505 [505]
Luggage capacity max. (seats down or roof up) in l
1,550 [1,550]
Trailer load (unbraked) in kg
750 [750]
Trailer load 8% (braked) in kg
1,800 [1,800]
Trailer load 12% (braked) in kg
1,800 [1,800]
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (PS) at 1/min
110 (150)/4,000
Engine torque (Nm) at 1/min
350/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
204 [204]
Acceleration 0–100 km/h in s
10.0 [10.2]
Fuel consumption
Urban in l/100 km
5.6-5.3 [5.6-5.1]
Extra-urban in l/100 km
4.5 [4.5]
Combined in l/100 km
5.0-4.8 [5.0-4.7]
CO2 combined emissions in g/km
131-125 [130-122]
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
225/55 R17 97W
Tyre dimensions rear
225/55 R17 97W
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,550
Max. permissible weight in kg
2,13
Permitted load in kg
580
Permitted axle load front/rear in kg
1,095/1,080
Luggage capacity min. (seats up or roof down) in l
505
Luggage capacity max. (seats down or roof up) in l
1,550
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (PS) at 1/min
140 (190)/4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
222
Acceleration 0–100 km/h in s
7.9
Fuel consumption
Urban in l/100 km
5.3-5.0
Extra-urban in l/100 km
4.4-4.1
Combined in l/100 km
4.7-4.4
CO2 combined emissions in g/km
124-116
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
225/55 R17 97W
Tyre dimensions rear
225/55 R17 97W
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1,615
Max. permissible weight in kg
2,200
Permitted load in kg
585
Permitted axle load front/rear in kg
1,115/1,120
Luggage capacity min. (seats up or roof down) in l
505
Luggage capacity max. (seats down or roof up) in l
1,550
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (PS) at 1/min
140 (190)/4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
219
Acceleration 0–100 km/h in s
7.8
Fuel consumption
Urban in l/100 km
5.6-5.3
Extra-urban in l/100 km
4.7-4.3
Combined in l/100 km
5.0-4.7
CO2 combined emissions in g/km
131-123
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
225/55 R17 97W
Tyre dimensions rear
225/55 R17 97W
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy

Fuel consumption and CO2 emissions.

  • BMW X1 xDrive20i:
    Fuel consumption in l/100 km (combined): 6.7–6.3
    CO2 emissions in g/km (combined): 152–143

    BMW X1 xDrive25e*:
    Fuel consumption in l/100 km (combined): 2.1–1.9
    CO2 emissions in g/km (combined): 48–43

    * Expected to be available from 03/2020. Provisional, not yet confirmed data, subject to change without notice.

    BMW X1 xDrive25e: temporary peak power 170 kW (231 hp). Duration of peak power increases as the ambient temperature decreases (approx. 5 s at +25°C, up to approx. 40 s at -20°C). This allows acceleration from 0-100 km/h in 6.9 s

    The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles cars can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from The Society of the Irish Motor Industry, 5 Upper Pembroke Street, Dublin 2.

    The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
