BMW 5 SERIES SALOON: ENGINES & TECHNICAL DATA.
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 5 Series Saloon.
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 5 Series Saloon.
BMW 5 SERIES SALOON: TECHNICAL DATA.
No search result found. Please try another input
- Steptronic transmission with gearshift paddles
- Steptronic transmission with gearshift paddles
- Steptronic Sport transmission
- Steptronic Sport transmission
- Steptronic Sport transmission
- Steptronic transmission with gearshift paddles
- Steptronic Sport transmission
- Steptronic Sport transmission
- Steptronic Sport transmission
- Steptronic transmission with gearshift paddles
- Steptronic Sport transmission
- Automatic
Fuel type | Driving electric and with petrol |
---|---|
System power in kW (hp) | 215 (292) "1" |
Max. Torque (Nm) | 420 "1" |
Gearbox | 8-speed, automatic |
Drive Type | rear wheel drive |
Electric power | 80 (109) |
---|---|
Nominal torque in Nm | 265 |
Cylinder/ Valves per cylinder | 4 / 4 |
---|---|
Technical capacity in cm3 | 1,998 |
Engine performance in kW (hp) | 135 (184) / 5000 - 6500 |
Max torque(Nm) per 1/min | 300 / 1350 - 4000 |
WLTP combined electric range in km | 53 - 60 |
---|---|
Max. charging performance AC in kW | 3.7 |
Charging time AC in h, e.g. at BMW Wallbox, 0-100% state of charge (SOC) | 3.75 |
Top Speed | 235 |
---|---|
Top Speed Electric | 140 |
Acceleration | 5.9 |
Length/Width/Height | 4,963 / 1,868 / 1,483 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12 |
Ground clearance in mm | 150 |
Weight not loaded in kg | 1,910 |
---|---|
Weight Max in kg | 2,505 |
Permitted load in kg | 670 |
Permitted Axle load front/rear in kg | 1,120 / 1,450 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 80 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 1,700 / 1,700 |
Trunk capacity min.-max. in l | 410 |
Tire front | 245/35 R20 95 Y XL |
---|---|
Tire rear | 275/30 R20 97 Y XL |
Rim front | 8Jx20 LM |
Rim rear | 9Jx20 LM |
Fuel consumption Weighted | 1.4 - 1.8 |
---|---|
Electric consumption AC Weighted | 16.6 - 18.1 |
Tank capacity in l | 46 |
CO2 weighted | 32 - 40 |
---|
Fuel type | Driving electric and with petrol |
---|---|
System power in kW (hp) | 215 (292) "1" |
Max. Torque (Nm) | 420 "1" |
Gearbox | 8-speed, automatic |
Drive Type | all wheel drive |
Electric power | 80 (109) |
---|---|
Nominal torque in Nm | 265 |
Cylinder/ Valves per cylinder | 4 / 4 |
---|---|
Technical capacity in cm3 | 1,998 |
Engine performance in kW (hp) | 135 (184) / 5000 - 6500 |
Max torque(Nm) per 1/min | 300 / 1350 - 4000 |
WLTP combined electric range in km | 48 - 54 |
---|---|
Max. charging performance AC in kW | 3.7 |
Charging time AC in h, e.g. at BMW Wallbox, 0-100% state of charge (SOC) | 3.75 |
Top Speed | 230 |
---|---|
Top Speed Electric | 140 |
Acceleration | 5.9 |
Length/Width/Height | 4,963 / 1,868 / 1,483 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12.4 |
Ground clearance in mm | 146 |
Weight not loaded in kg | 1,970 |
---|---|
Weight Max in kg | 2,560 |
Permitted load in kg | 665 |
Permitted Axle load front/rear in kg | 1,170 / 1,455 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 80 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 2,000 / 2,000 |
Trunk capacity min.-max. in l | 410 |
Tire front | 245/35 R20 95 Y XL |
---|---|
Tire rear | 275/30 R20 97 Y XL |
Rim front | 8Jx20 LM |
Rim rear | 9Jx20 LM |
Fuel consumption Weighted | 1.7 - 2.1 |
---|---|
Electric consumption AC Weighted | 17.7 - 19.2 |
Tank capacity in l | 46 |
CO2 weighted | 38 - 48 |
---|
Fuel type | Driving electric and with petrol |
---|---|
System power in kW (hp) | 290 (394) "1" |
Max. Torque (Nm) | 600 "1" |
Gearbox | 8-speed, automatic |
Drive Type | all wheel drive |
Electric power | 80 (109) |
---|---|
Nominal torque in Nm | 265 |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Technical capacity in cm3 | 2,998 |
Engine performance in kW (hp) | 210 (286) / 5000 - 6000 |
Max torque(Nm) per 1/min | 450 / 1600 - 3500 |
WLTP combined electric range in km | 47 - 54 |
---|---|
Max. charging performance AC in kW | 3.7 |
Charging time AC in h, e.g. at BMW Wallbox, 0-100% state of charge (SOC) | 3.75 |
Top Speed | 250 |
---|---|
Top Speed Electric | 140 |
Acceleration | 4.6 |
Length/Width/Height | 4,963 / 1,868 / 1,483 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12.4 |
Ground clearance in mm | 146 |
Weight not loaded in kg | 2,020 |
---|---|
Weight Max in kg | 2,605 |
Permitted load in kg | 660 |
Permitted Axle load front/rear in kg | 1,205 / 1,455 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 80 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 2,000 / 2,000 |
Trunk capacity min.-max. in l | 410 |
Tire front | 245/35 R20 95 Y XL |
---|---|
Tire rear | 275/30 R20 97 Y XL |
Rim front | 8Jx20 LM |
Rim rear | 9Jx20 LM |
Fuel consumption Weighted | 1.8 - 2.2 |
---|---|
Electric consumption AC Weighted | 17.7 - 19.1 |
Tank capacity in l | 46 |
CO2 weighted | 41 - 50 |
---|
Fuel type | Driving electric and with petrol |
---|---|
System power in kW (hp) | 215 (292) "1" |
Max. Torque (Nm) | 420 "1" |
Gearbox | 8-speed, automatic |
Drive Type | rear wheel drive |
Electric power | 80 (109) |
---|---|
Nominal torque in Nm | 265 |
Cylinder/ Valves per cylinder | 4 / 4 |
---|---|
Technical capacity in cm3 | 1,998 |
Engine performance in kW (hp) | 135 (184) / 5000 - 6500 |
Max torque(Nm) per 1/min | 300 / 1350 - 4000 |
WLTP combined electric range in km | 58 - 60 |
---|---|
Max. charging performance AC in kW | 3.7 |
Charging time AC in h, e.g. at BMW Wallbox, 0-100% state of charge (SOC) | 3.75 |
Top Speed | 235 |
---|---|
Top Speed Electric | 140 |
Acceleration | 5.9 |
Length/Width/Height | 4,963 / 1,868 / 1,483 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12 |
Ground clearance in mm | 150 |
Weight not loaded in kg | 1,910 |
---|---|
Weight Max in kg | 2,505 |
Permitted load in kg | 670 |
Permitted Axle load front/rear in kg | 1,120 / 1,450 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 80 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 1,700 / 1,700 |
Trunk capacity min.-max. in l | 410 |
Tire front | 225/55 R17 101 Y XL |
---|---|
Tire rear | 225/55 R17 101 Y XL |
Rim front | 7,5Jx17 LM |
Rim rear | 7,5Jx17 LM |
Fuel consumption Weighted | 1.4 - 1.5 |
---|---|
Electric consumption AC Weighted | 16.5 - 17.1 |
Tank capacity in l | 46 |
CO2 weighted | 31 - 35 |
---|
Fuel type | Driving electric and with petrol |
---|---|
System power in kW (hp) | 215 (292) "1" |
Max. Torque (Nm) | 420 "1" |
Gearbox | 8-speed, automatic |
Drive Type | all wheel drive |
Electric power | 80 (109) |
---|---|
Nominal torque in Nm | 265 |
Cylinder/ Valves per cylinder | 4 / 4 |
---|---|
Technical capacity in cm3 | 1,998 |
Engine performance in kW (hp) | 135 (184) / 5000 - 6500 |
Max torque(Nm) per 1/min | 300 / 1350 - 4000 |
WLTP combined electric range in km | 52 - 54 |
---|---|
Max. charging performance AC in kW | 3.7 |
Charging time AC in h, e.g. at BMW Wallbox, 0-100% state of charge (SOC) | 3.75 |
Top Speed | 230 |
---|---|
Top Speed Electric | 140 |
Acceleration | 5.9 |
Length/Width/Height | 4,963 / 1,868 / 1,483 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12.4 |
Ground clearance in mm | 146 |
Weight not loaded in kg | 1,970 |
---|---|
Weight Max in kg | 2,560 |
Permitted load in kg | 665 |
Permitted Axle load front/rear in kg | 1,170 / 1,455 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 80 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 2,000 / 2,000 |
Trunk capacity min.-max. in l | 410 |
Tire front | 225/55 R17 101 Y XL |
---|---|
Tire rear | 225/55 R17 101 Y XL |
Rim front | 7,5Jx17 LM |
Rim rear | 7,5Jx17 LM |
Fuel consumption Weighted | 1.6 - 1.8 |
---|---|
Electric consumption AC Weighted | 17.6 - 18.2 |
Tank capacity in l | 46 |
CO2 weighted | 37 - 41 |
---|
Fuel type | Driving electric and with petrol |
---|---|
System power in kW (hp) | 290 (394) "1" |
Max. Torque (Nm) | 600 "1" |
Gearbox | 8-speed, automatic |
Drive Type | all wheel drive |
Electric power | 80 (109) |
---|---|
Nominal torque in Nm | 265 |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Technical capacity in cm3 | 2,998 |
Engine performance in kW (hp) | 210 (286) / 5000 - 6000 |
Max torque(Nm) per 1/min | 450 / 1600 - 3500 |
WLTP combined electric range in km | 53 - 55 |
---|---|
Max. charging performance AC in kW | 3.7 |
Charging time AC in h, e.g. at BMW Wallbox, 0-100% state of charge (SOC) | 3.75 |
Top Speed | 250 |
---|---|
Top Speed Electric | 140 |
Acceleration | 4.6 |
Length/Width/Height | 4,963 / 1,868 / 1,483 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12.4 |
Ground clearance in mm | 146 |
Weight not loaded in kg | 2,020 |
---|---|
Weight Max in kg | 2,605 |
Permitted load in kg | 660 |
Permitted Axle load front/rear in kg | 1,205 / 1,455 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 80 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 2,000 / 2,000 |
Trunk capacity min.-max. in l | 410 |
Tire front | 225/55 R17 101 Y XL |
---|---|
Tire rear | 225/55 R17 101 Y XL |
Rim front | 7,5Jx17 LM |
Rim rear | 7,5Jx17 LM |
Fuel consumption Weighted | 1.7 - 1.9 |
---|---|
Electric consumption AC Weighted | 17.5 - 18.1 |
Tank capacity in l | 46 |
CO2 weighted | 39 - 43 |
---|
Fuel type | Petrol – 48 Volt Mild-Hybrid |
---|---|
System power in kW (hp) | 135 (184) |
Max. Torque (Nm) | 290 |
Gearbox | 8-speed, automatic |
Drive Type | rear wheel drive |
Electric power | 8 (11) |
---|
Cylinder/ Valves per cylinder | 4 / 4 |
---|---|
Technical capacity in cm3 | 1,998 |
Engine performance in kW (hp) | 135 (184) / 5000 - 6500 |
Max torque(Nm) per 1/min | 290 / 1350 - 4250 |
Top Speed | 235 |
---|---|
Acceleration | 7.9 |
Length/Width/Height | 4,963 / 1,868 / 1,479 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12 |
Ground clearance in mm | 144 |
Weight not loaded in kg | 1,685 |
---|---|
Weight Max in kg | 2,285 |
Permitted load in kg | 675 |
Permitted Axle load front/rear in kg | 1,080 / 1,280 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 90 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 2,000 / 2,000 |
Trunk capacity min.-max. in l | 530 |
Tire front | 245/35 R20 95 Y XL |
---|---|
Tire rear | 275/30 R20 97 Y XL |
Rim front | 8Jx20 LM |
Rim rear | 9Jx20 LM |
Fuel Consumption charge sustaining combined | 6.3 - 6.9 |
---|---|
Tank capacity in l | 68 |
CO2 charge sustaining combined | 144 - 157 |
---|
Fuel type | Petrol – 48 Volt Mild-Hybrid |
---|---|
System power in kW (hp) | 135 (184) |
Max. Torque (Nm) | 290 |
Gearbox | 8-speed, automatic |
Drive Type | rear wheel drive |
Electric power | 8 (11) |
---|
Cylinder/ Valves per cylinder | 4 / 4 |
---|---|
Technical capacity in cm3 | 1,998 |
Engine performance in kW (hp) | 135 (184) / 5000 - 6500 |
Max torque(Nm) per 1/min | 290 / 1350 - 4250 |
Top Speed | 235 |
---|---|
Acceleration | 7.9 |
Length/Width/Height | 4,963 / 1,868 / 1,479 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12 |
Ground clearance in mm | 144 |
Weight not loaded in kg | 1,685 |
---|---|
Weight Max in kg | 2,285 |
Permitted load in kg | 675 |
Permitted Axle load front/rear in kg | 1,080 / 1,280 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 90 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 2,000 / 2,000 |
Trunk capacity min.-max. in l | 530 |
Tire front | 225/55 R17 101 Y XL |
---|---|
Tire rear | 225/55 R17 101 Y XL |
Rim front | 7,5Jx17 LM |
Rim rear | 7,5Jx17 LM |
Fuel Consumption charge sustaining combined | 6.2 - 6.5 |
---|---|
Tank capacity in l | 68 |
CO2 charge sustaining combined | 142 - 149 |
---|
Fuel type | Petrol |
---|---|
System power in kW (hp) | 390 (530) |
Max. Torque (Nm) | 750 |
Gearbox | 8-speed, automatic |
Drive Type | all wheel drive |
Cylinder/ Valves per cylinder | 8 / 4 |
---|---|
Technical capacity in cm3 | 4,395 |
Engine performance in kW (hp) | 390 (530) / 5500 - 6000 |
Max torque(Nm) per 1/min | 750 / 1800 - 4600 |
Top Speed | 250 |
---|---|
Acceleration | 3.8 |
Length/Width/Height | 4,972 / 1,868 / 1,467 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12.4 |
Ground clearance in mm | 131 |
Weight not loaded in kg | 1,990 |
---|---|
Weight Max in kg | 2,560 |
Permitted load in kg | 645 |
Permitted Axle load front/rear in kg | 1,260 / 1,365 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 90 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 2,000 / 2,000 |
Trunk capacity min.-max. in l | 530 |
Tire front | 245/40 R19 98 Y XL |
---|---|
Tire rear | 275/35 R19 100 Y XL |
Rim front | 8Jx19 LM |
Rim rear | 9Jx19 LM |
Combined in l/100km | 10.6 - 10.8 |
---|---|
Tank capacity in l | 68 |
Combined in g/km | 243 - 247 |
---|
Fuel type | Petrol |
---|---|
System power in kW (hp) | 460 (625) |
Max. Torque (Nm) | 750 |
Gearbox | 8-speed, automatic |
Drive Type | all wheel drive |
Cylinder/ Valves per cylinder | 8 / 4 |
---|---|
Technical capacity in cm3 | 4,395 |
Engine performance in kW (hp) | 460 (625) / 6,000 |
Max torque(Nm) per 1/min | 750 / 1800 - 5860 |
Top Speed | 250 |
---|---|
Acceleration | 3.3 |
Length/Width/Height | 4,983 / 1,903 / 1,469 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,982 / 12.6 |
Ground clearance in mm | 120 |
Weight not loaded in kg | 1,970 |
---|---|
Weight Max in kg | 2,440 |
Permitted load in kg | 545 |
Permitted Axle load front/rear in kg | 1,215 / 1,260 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 90 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 2,000 / 2,000 |
Trunk capacity min.-max. in l | 530 |
Tire front | 275/35 ZR20 (102Y) XL |
---|---|
Tire rear | 285/35 ZR20 (104Y) XL |
Rim front | 9,5J x 20 |
Rim rear | 10,5J x 20 |
Combined in l/100km | 11.1 - 11.3 |
---|---|
Tank capacity in l | 68 |
Combined in g/km | 254 - 258 |
---|
Fuel type | Diesel – 48 Volt Mild-Hybrid |
---|---|
System power in kW (hp) | 140 (190) |
Max. Torque (Nm) | 400 |
Gearbox | 8-speed, automatic |
Drive Type | rear wheel drive |
Electric power | 8 (11) |
---|
Cylinder/ Valves per cylinder | 4 / 4 |
---|---|
Technical capacity in cm3 | 1,995 |
Engine performance in kW (hp) | 140 (190) / 4,000 |
Max torque(Nm) per 1/min | 400 / 1750 - 2500 |
Top Speed | 235 |
---|---|
Acceleration | 7.2 |
Length/Width/Height | 4,963 / 1,868 / 1,479 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12 |
Ground clearance in mm | 144 |
Weight not loaded in kg | 1,750 |
---|---|
Weight Max in kg | 2,345 |
Permitted load in kg | 670 |
Permitted Axle load front/rear in kg | 1,100 / 1,320 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 90 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 2,000 / 2,000 |
Trunk capacity min.-max. in l | 530 |
Tire front | 245/35 R20 95 Y XL |
---|---|
Tire rear | 275/30 R20 97 Y XL |
Rim front | 8Jx20 LM |
Rim rear | 9Jx20 LM |
Fuel Consumption charge sustaining combined | 4.9 - 5.5 |
---|---|
Tank capacity in l | 66 |
CO2 charge sustaining combined | 128 - 143 |
---|
Fuel type | Diesel – 48 Volt Mild-Hybrid |
---|---|
System power in kW (hp) | 140 (190) |
Max. Torque (Nm) | 400 |
Gearbox | 8-speed, automatic |
Drive Type | rear wheel drive |
Electric power | 8 (11) |
---|
Cylinder/ Valves per cylinder | 4 / 4 |
---|---|
Technical capacity in cm3 | 1,995 |
Engine performance in kW (hp) | 140 (190) / 4,000 |
Max torque(Nm) per 1/min | 400 / 1750 - 2500 |
Top Speed | 235 |
---|---|
Acceleration | 7.2 |
Length/Width/Height | 4,963 / 1,868 / 1,479 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2126 (1069 / 1057) |
Wheelbase in mm/Wheel turn in m | 2,975 / 12 |
Ground clearance in mm | 144 |
Weight not loaded in kg | 1,750 |
---|---|
Weight Max in kg | 2,345 |
Permitted load in kg | 670 |
Permitted Axle load front/rear in kg | 1,100 / 1,320 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 90 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 2,000 / 2,000 |
Trunk capacity min.-max. in l | 530 |
Tire front | 225/55 R17 101 Y XL |
---|---|
Tire rear | 225/55 R17 101 Y XL |
Rim front | 7,5Jx17 LM |
Rim rear | 7,5Jx17 LM |
Fuel Consumption charge sustaining combined | 4.8 - 5.1 |
---|---|
Tank capacity in l | 66 |
CO2 charge sustaining combined | 126 - 133 |
---|
FUEL CONSUMPTION AND CO2 EMISSIONS.
BMW 530e**:
Fuel consumption in l/100 km (combined): 1,8–1,3
CO2 emissions in g/km (combined): 41–30
Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.
Fuel consumption and CO2 emissions.
BMW 530e**:
Fuel consumption in l/100 km (combined): 1.7–1.3
CO2 emissions in g/km (combined): 39–30
Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.
