THE BMW 3 SERIES SALOON: ENGINES & TECHNICAL DATA

THE 3THE BMW 3 SERIES SALOON: ENGINES & TECHNICAL DATA

TECHNICAL DATA OF THE BMW 3 SERIES SALOON.

Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,570
Max. permissible weight in kg
2,050
Permitted load in kg
555
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,600
Trailer load 12% (braked) in kg
1,600
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
135(184)/5,000-6,500
Engine torque (Nm) at 1/min
300/1,350-4,000
Compression ratio : 1
11.0
Performance
Top speed in km/h
235
Acceleration 0–100 km/h in s
7.1
Fuel consumption
Urban in l/100 km
7.1-6.6
Extra-urban in l/100 km
4.9-4.5
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,545
Max. permissible weight in kg
2,060
Permitted load in kg
590
Permitted axle load front/rear in kg
985/1,160
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,600
Trailer load 12% (braked) in kg
1,600
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
190 (258)/5,000-6,500
Engine torque (Nm) at 1/min
400/1,550-4,400
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.8
Fuel consumption
Urban in l/100 km
7.4-7.1
Extra-urban in l/100 km
5.3-5.0
Combined in l/100 km
6.1-5.8
CO2 combined emissions in g/km
138-132
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98Y XL
Tyre dimensions rear
225/50 R17 98Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,560 [1,580]
Max. permissible weight in kg
2,075 [2,085]
Permitted load in kg
590 [580]
Permitted axle load front/rear in kg
965/1,180 [965/1,180]
Luggage capacity min. (seats up or roof down) in l
480 [480]
Luggage capacity max. (seats down or roof up) in l
- [-]
Trailer load (unbraked) in kg
750 [750]
Trailer load 8% (braked) in kg
1,600 [1,600]
Trailer load 12% (braked) in kg
1,600 [1,600]
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
110 (150)/4,000
Engine torque (Nm) at 1/min
320/1,500-3,000
Compression ratio : 1
16.5
Performance
Top speed in km/h
226 [224]
Acceleration 0–100 km/h in s
8.4 [8.3]
Fuel consumption
Urban in l/100 km
5.4-5.2 [4.9-4.7]
Extra-urban in l/100 km
4.0-3.6 [4.1-3.8]
Combined in l/100 km
4.5-4.2 [4.4-4.1]
CO2 combined emissions in g/km
119-110 [115-108]
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
40
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,570 [1,570]
Max. permissible weight in kg
2,075 [2,085]
Permitted load in kg
580 [590]
Permitted axle load front/rear in kg
970/1,180 [970/1,180]
Luggage capacity min. (seats up or roof down) in l
480 [480]
Luggage capacity max. (seats down or roof up) in l
- [-]
Trailer load (unbraked) in kg
750 [750]
Trailer load 8% (braked) in kg
1,600 [1,600]
Trailer load 12% (braked) in kg
1,600 [1,600]
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
140 (190)/4,000-4,000
Engine torque (Nm) at 1/min
400/1,750-2,250
Compression ratio : 1
16.5
Performance
Top speed in km/h
240 [240]
Acceleration 0–100 km/h in s
7.1 [6.8]
Fuel consumption
Urban in l/100 km
5.6-5.2 [5.8-4.5]
Extra-urban in l/100 km
4.0-3.7 [4.0-3.7]
Combined in l/100 km
4.6-4.3 [4.3-4.0]
CO2 combined emissions in g/km
121-113 [112-105]
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
40
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,655
Max. permissible weight in kg
2,170
Permitted load in kg
590
Permitted axle load front/rear in kg
1,055/1,195
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
140 (190)/4,000-4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
233
Acceleration 0–100 km/h in s
6.9
Fuel consumption
Urban in l/100 km
5.2-5.0
Extra-urban in l/100 km
4.3-4.0
Combined in l/100 km
4.6-4.3
CO2 combined emissions in g/km
122-114
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
40
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,665
Max. permissible weight in kg
2,185
Permitted load in kg
595
Permitted axle load front/rear in kg
1,075/1,210
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
195(265)/4,000-4,000
Engine torque (Nm) at 1/min
580/1,750-2,750
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.5
Fuel consumption
Urban in l/100 km
6.3-6.1
Extra-urban in l/100 km
4.6-4.2
Combined in l/100 km
5.2-4.9
CO2 combined emissions in g/km
137-130
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
Weight
Unladen weight EU in kg
1,735
Max. permissible weight in kg
2,255
Permitted load in kg
595
Permitted axle load front/rear in kg
1,105/1,230
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
195(265)/4,000-4,000
Engine torque (Nm) at 1/min
580/1,750-2,750
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.1
Fuel consumption
Urban in l/100 km
6.4
Extra-urban in l/100 km
4.7-4.4
Combined in l/100 km
5.4-5.1
CO2 combined emissions in g/km
140-134
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,635
Max. permissible weight in kg
2,130
Permitted load in kg
570
Permitted axle load front/rear in kg
1,050/1,185
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
135(184)/5,000-6,500
Engine torque (Nm) at 1/min
300/1,350-4,000
Compression ratio : 1
11.0
Performance
Top speed in km/h
230
Acceleration 0–100 km/h in s
7.6
Fuel consumption
Urban in l/100 km
7.8-7.3
Extra-urban in l/100 km
5.6-5.2
Combined in l/100 km
6.4-5.9
CO2 combined emissions in g/km
146-135
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,640
Max. permissible weight in kg
2,155
Permitted load in kg
590
Permitted axle load front/rear in kg
1,055/1,195
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
190(258)/5,000-6,500
Engine torque (Nm) at 1/min
400/1,550-4,400
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.5
Fuel consumption
Urban in l/100 km
8.0-7.4
Extra-urban in l/100 km
5.6-5.2
Combined in l/100 km
6.4-6.0
CO2 combined emissions in g/km
146-137
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,745
Max. permissible weight in kg
2,245
Permitted load in kg
575
Permitted axle load front/rear in kg
1,115/1,230
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,800
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
275(374)/5,500-6,500
Engine torque (Nm) at 1/min
500/1,850-5,000
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.4
Fuel consumption
Urban in l/100 km
9.6-9.2
Extra-urban in l/100 km
6.1-5.7
Combined in l/100 km
7.3-7.0
CO2 combined emissions in g/km
167-159
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/45 R18 95Y XL
Tyre dimensions rear
255/40 R18 99Y XL
Wheel dimensions and material front
7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear
8.5 J x 18 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
