TECHNICAL DATA OF THE BMW 3 SERIES SALOON.

BMW 318i Saloon
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,565
Max. permissible weight in kg
2,050
Permitted load in kg
560
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,300
Trailer load 12% (braked) in kg
1,300
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
115(156)/4,500-6,500
Engine torque (Nm) at 1/min
250/1,300-4,300
Compression ratio : 1
11.0
Performance
Top speed in km/h
223
Acceleration 0–100 km/h in s
8.4
Fuel consumption
Urban in l/100 km
7.0-6.7
Extra-urban in l/100 km
4.9-4.4
Combined in l/100 km
5.7-5.3
CO2 combined emissions in g/km
130-120
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96 W XL
Tyre dimensions rear
205/60 R16 96 W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
